Main Features

1. Ultra-high-fidelity sound, pleasant stereo sound
2. Ultrathin and ultra-light hardware case, delicate and beautiful
3. Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill!
4. Verity and complete software, stable and reliable
5. Have a lock, anti-theft functions
6. Widely used in the bus, building and lift room, supermarket, pubic places, train etc

Specification

Model No.

US-AD550LF,US-AD550NF

Panel size

55″ TFT-LCD

Display area(mm)/mode

1209.6×680.4 16:9

Maximum resolution

1920*1080

Display color

16.7M

Pixel Pitch(mm)

0.63(H)×0.63(V)

Brightness (nits)

500cd/m2

Contrast

1000:1

Visual angle

178°/178°

Response time

5ms

Life(hrs)

>60,000(hrs)

Input and output

RJ45

Included(Network version only)

3G / WIFI Module

Included(Network version only)

USB

1 ( USB2.0 interface)

SD

1 (Compatible MMC/MS)

CF

1(optional)

L/R audio input

1 (RCA*2)

L/R audio output

1 (RCA*2)

Speaker

2×5W(9Ω)

Video

Color system

PAL/NTSC/SECAM

Remote controller

IR Remote Controller

OSD display( screen menu display)

Menu language

Chinese/English( Multiple Language Supported)

Power

Power supply

AC100~240V 50 /60 HZ

Maximum power consumption

<=280W

Standby power consumption

<5W

Temperature

Working temperature

0°C~50°C

Storage temperature

-20°C~60°C

Working humidity

20%~85%

Storage humidity

10%~90%

Appearance

Color/appearance

White,black,customized

Body Dimension

1900(H)*886.78(L)*90(W)mm

After packing size

1990mm×1030mm×250mm

Case

Metal case SPCC

Installation

Floor-standing

Gross Weight

108kg

Quality Standard

ISO9001,CCC

Detailed functions

Video format

MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI

Audio format

Wave/MP3/WMA/AAC

Image format

JPEG/BMP/TIFF/PNG/GIF

Image resolution

480P/720P/1080P

Sample Leading time

3~5 working days

Bulk Order Leading time

10~ 12 working days

Payment term

T/T---100% payment before production for sample,30% payment before production and 70% balance before shipping for bulk order.

Warranty

1year

Transportation way

By Express, by air, by sea
