High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
Specifications
Displacement :
Other
Pump Type :
Piston Pump
Warranty :
1 Year
Brand Name :
Parker
Place of Origin :
Hubei, China
Connection Size :
1/4 inch
Dimension(L*W*H) :
40x40x40
Max. Horsepower :
0.5 HP
Maximum Flow Rate :
1500
Number of stages :
1 Stage
Operating Pressure :
100 bar
Power(W) :
3500
Pressure :
35, High Pressure
Showroom Location :
Chile
Structure :
Plunger Pump, Single-stage Pump
Weight :
40
Type :
Hydrulaic Pump
Product name :
Hydraulic Hose Fittings
Standard or Nonstandard :
Standard Hydraulic
Application :
Machinery
Material :
Carbon Steel
Usage :
Hdyraulic
MOQ :
1 Piece
After Warranty Service :
Online Support
MOQ :
1 ton
Price :
$110-120 / ton
Description

High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00Maximum vacuum flow rate: n/a
working pressure: 280 bar, 4000 psi
Technology: Hydraulics
Current Speed: 250 L/min, 66 gal/min
Displacement: 140 cm3/rev, 8.5 inch3/rev
Valve body material: cast iron
Drainage options: Yes
Including supply pump: No
Circuit path: normally open
Configuration: Single/Serial/Multiple, Tandem, Multiple
Control method: pressure limiter | load sensitive | electronic control | unloading | proportional | fan drive, Load Sense, Electronic Control, Unloading, Proportiona, Fan Drive
Energy recovery capability: Yes
Including filters: No
Used together with fluid type: standard hydraulic oil
Maximum displacement: 140 cm3/rev, 8.5 inch3/rev
Maximum flow rate: 66 gal/min, 250 L/min
Maximum fluid temperature: 95 ° C, 200 °F
Minimum fluid temperature: -40 ° C- 40 °F
Maximum noise level: 83 dBA
Maximum operating pressure: 280 bar, 4000 psi
Radial load capacity: 160-594 lb-ft
Maximum working speed: 1800 RPM
Maximum kinematic viscosity: NA
Minimum kinematic viscosity: NA
Weight: 82 kg (Max), 180 lb (Max)
Medium: Hydraulic / Liquid, Hydraulic Fluids, Liquids
Installation plan: SAE | ISO |BSPP, ISO
Port connection: SAE | ISO | BSPP, ISO, BSPP
Port type: flange | straight thread, Straight Threaded
Port position: Side port | Rear port | Oppose port, Rear Ports, Opposing Ports
Pump type: plunger
Rotation direction: clockwise | counterclockwise, Counterclockwise
Sensor type: NA
Axis type: SAE | ISO |BSPP, ISO
Direct drive capability: YesHigh-pressure Plunger Pump PD140PS02SRS5AC00S100PB00

High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00High-pressure Plunger Pump PD140PS02SRS5AC00S100PB00
