Table Top Series CO2 Laser Rubber Marking Machine
Table Top Series CO2 Laser Rubber Marking Machine
Specifications
Production Capacity :
100000
MOQ :
1 Piece
HS Code :
8456301090
Price :
US $6,000-8,000 / P
Trademark :
HBS Laser
Laser Source :
Coherent From USA
Transport Package :
Cartons
Marking Method :
Scanning Marking
Specification :
1000*880*380mm
Cooling System :
Air Cooling
Technical Class :
Pulse Laser
Type :
CO2 Laser Marking Machine
Origin :
China Beijing
Model NO. :
HBS-CO2-30
Laser Wavelength :
CO2 Laser
Laser Classification :
Gaseous Laser
Description
Table Top Series CO2 Laser Rubber Marking Machine
HBS-CO2-30 fiber laser marking machine for plastic, rubber, paper, wood marking

Laser Wavelength

1060nm

Beam Quality

<1.5

Laser Repetition

≤70KHz

Standard Marking Area

300mm x 300mm

Making Depth

≤2mm (Adjustable)

Marking Speed

≤7000mm/s

Min. Line Width

0.03mm

Min. Character Size

0.3mm

Repetition Precision

±0.001mm

Power Consumption

≤1.2kw

Cooling method

Air cooled

Power Supply

220V/50Hz/10A
Optional Lens

Lens Type

HBS-65

HBS-110

HBS-175

Focal Length

100mm

170mm

250mm

Marking Area

65mm*65mm

110mm*110mm

175mm*175mm

Note: Without special request, HBS will fix our standard lens with Model: HBS-110
Table Top Series CO2 Laser Rubber Marking Machine
Product Introduction
  • HBS CO2 Laser Marking Machine is specially designed for non-metallic materials marking. It is equipped with the original imported American CO2 laser and high-speed galvanometer with unique fully sealed cavity construction.
  • The working principle: fill the discharge tube with CO2 gas as a lasing medium, when high voltage is applied to the electrodes, radiant discharge is generated in the discharge tube, causing the gas molecules to release the laser. After amplification, the laser beam is released for material processing. With computer controlling the galvanometer, the laser beam is adjusted for automatic marking.
  • Table Top Series CO2 Laser Rubber Marking Machine
Product Features
  • High-precision marking, high speed operation, control marking depth freely.
  • No pollution, no consumables.
  • Marking software runs on WINDOWS XP platform, English or Chinese interface, compatible software such as AUTOCAD, CORELDRAW, PHOTO-SHOP and various formats such as PLT, PCW, DXF, BMP etc. It can also directly access to SHX, TTF fonts library and able to work freely on graphic design.
Product Application
  • Mainly used in non-metallic industry including tobacco, food and beverage, wine, pharmaceutical packaging, leather, plastics, polymers, wooden products, jade, agate and other non-metallic materials.
  • Table Top Series CO2 Laser Rubber Marking Machine Table Top Series CO2 Laser Rubber Marking Machine Table Top Series CO2 Laser Rubber Marking Machine
