Specifications
Laser Wavelength :
CO2 Laser
Condition :
New
Transport Package :
Cartons
Control Software :
Ezcad
Trademark :
HBS
MOQ :
1 Piece
Power :
20W, 30W, 50W
Graphic Format :
Ai, BMP, Dxf, Dxp, Las, Plt
Laser Classification :
Gaseous Laser
Laser Source :
Raycus
Type :
Optical Fiber Laser Marking Machine
Laser Type :
CO2 Laser
Cooling System :
Air Cooling
Origin :
Beijing
HS Code :
8456301090
Marking Depth :
0-0.5mm (According)
Production Capacity :
50000 Pieces/Year
Technical Class :
Continuous Wave Laser
Marking Speed :
0-7000mm/S
Working Accuracy :
0.01
Price :
US $5,500-12,000 /
Marking Method :
Scanning Marking
Specification :
1000*880*380mm
Model NO. :
HBS-CO2-20
Certification :
CCC, Ce, ISO, SGS
Description

CO2 Laser Marking Machine Marking for non-Metals

2 years guarantee and life-time after sales service

1. Introduction
  • HBS CO2 Laser Marking Machine is specially designed for non-metallic materials marking. It is equipped with the original imported American CO2 laser and high-speed galvanometer with unique fully sealed cavity construction.
  • The working principle: fill the discharge tube with CO2 gas as a lasing medium, when the high voltage is applied to the electrodes, radiant discharge is generated in the discharge tube, causing the gas molecules to release the laser. After amplification, the laser beam is released for material processing. With the computer controlling the galvanometer, the laser beam is adjusted for automatic marking.
2. Technical Parameters

Laser Wavelength

1060nm

Beam Quality

<1.5

Laser Repetition

≤70KHz

Standard Marking Area

300mm x 300mm

Making Depth

≤2mm (Adjustable)

Marking Speed

≤7000mm/s

Min. Line Width

0.03mm

Min. Character Size

0.3mm

Repetition Precision

±0.001mm

Power Consumption

≤1.2kw

Cooling method

Air cooled

Power Supply

220V/50Hz/10A

Optional Lens

Lens Type

HBS-65

HBS-110

HBS-175

Focal Length

100mm

170mm

250mm

Marking Area

65mm*65mm

110mm*110mm

175mm*175mm

Note: Without special request, HBS will fix our standard lens with Model: HBS-110
3.Products Features
  • High-precision marking, high-speed operation, control marking depth freely.
  • No pollution, no consumables.
  • Marking software runs on WINDOWS XP platform, English or Chinese interface, compatible software such as AUTOCAD, CORELDRAW, PHOTO-SHOP and various formats such as PLT, PCW, DXF, BMP etc. It can also directly access to SHX, TTF fonts library and able to work freely on graphic design.
4.Product Application:

Mainly used in non-metallic industry including tobacco, food and beverage, wine, pharmaceutical packaging, leather, plastics, polymers, wooden products, jade, agate and other non-metallic materials.

5. Marking samples of Laser Marking

New 20W CO2 Making Machine Marking on Plastic Bottle
New 20W CO2 Making Machine Marking on Plastic Bottle
New 20W CO2 Making Machine Marking on Plastic Bottle

6. Our Company

New 20W CO2 Making Machine Marking on Plastic Bottle
New 20W CO2 Making Machine Marking on Plastic Bottle
New 20W CO2 Making Machine Marking on Plastic Bottle
