Specifications
Cooling System :
Air Cooling
Transport Package :
Cartons
Model NO. :
HBS-GQ-20 cabinet
Specification :
880*1000*1200mm
Laser Classification :
Solid Laser
Power :
20W, 30W, 50W
Condition :
New
Marking Method :
Scanning Marking
Working Accuracy :
0.01
Graphic Format :
Ai, BMP, Dxf, Dxp, Las, Plt
Laser Source :
Raycus or Ipg
Marking Speed :
0-12000mm/S
Type :
Optical Fiber Laser Marking Machine
Control Software :
Ezcad
MOQ :
1 Piece
Trademark :
HBS
Technical Class :
Continuous Wave Laser
Certification :
CCC, Ce, ISO, SGS
Laser Wavelength :
Fiber Laser
Origin :
Beijing
Laser Type :
Fiber Laser
HS Code :
8456110090
Marking Depth :
0-0.5mm (According)
Price :
US $2,000-3,500 / P
Production Capacity :
50000 Pieces/Year
Description
Hot selling Table Design Fiber laser marking machine

One year guarantee and life-time after sales service

Table Top 20W 30W Fiber Laser Jewelry Engraving Machine

1.Despriction of the Fiber Laser marking machine HBS-GQ-20

Fiber Laser Marking Machine is the latest generation of laser marking system, resulting from our own research using the world's most advanced laser technology.

Adoption of fiber laser system for outputting laser, and then achieve marking functions by high-speed scanning galvanometer mirror system.

The electro-optical conversion efficiency of fiber laser marking can reach 90% or above, it has higher beam quality in comparison to semiconductor laser marking machine.

The machine is designed for long-time maintenance-free.

2. Detailed Technical Information of fiber laser marking machine

Laser Wavelength

1060nm

Beam Quality

<1.5

Laser Repetition

≤100KHz

Standard Marking Area

110mm x 110mm; Max:300mmx300mm

Making Depth

≤1.5mm(Can be Adjustable)

Marking Speed

≤12000mm/s

Min. Line Width

0.01mm

Min. Character Size

0.05mm

Repetition Precision

±0.001mm

Power Consumption

≤500W

Cooling method

Air cooled

Power Supply

220V/50Hz/10A
Optional Lens

Lens Type

HBS-65

HBS-110

HBS-175

Focal Length

100mm

170mm

250mm

Marking Area

65mm*65mm

110mm*110mm

175mm*175mm

Note: Without special request, HBS will fix our standard lens Model: HBS-110
3.Product Features of the fiber laser marking machine
  • Extremely fast, with the high-speed galvanometer.
  • Small volume, lightweight.
  • No consumables, low power consumption, less than 500W.
  • Completely air cooled, do not need water chiller, lower power consumption.
  • Robust under harsh environment and temperature change can operate with batteries or supply from an automobile ci-garette lighter in case of power failure.
  • Low product depreciation cost. Ability to meet customers' mass and stable production.
4.Application of the fiber laser marking machine

The machine is assembled with fiber laser from Germany or Britain or RAYCUS. The working time can reach 100,000 hours or above, competent in different work locations.

Fiber laser marking machines are used in a wide variety of applications such as in the marking of gold, silver diamond and other jewelries, sanitary tools, food packaging, tobacco packaging, beer and beverage packaging, pharmaceutical packaging, medical equipments, watches & glassware, automotive parts, plastic & paper material, electronic hardware, gold bullion, and also in other areas suchs as aviation, aircraft manufacturing, projectile body and explosion proof materials.

5. Marking samples of Laser marking HBS-GQ-20

Table Top 20W 30W Fiber Laser Jewelry Engraving Machine

6. Our Company

Table Top 20W 30W Fiber Laser Jewelry Engraving Machine

Table Top 20W 30W Fiber Laser Jewelry Engraving Machine

Table Top 20W 30W Fiber Laser Jewelry Engraving Machine
