Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Specifications
Technical Class :
Pulse Laser
Marking Method :
Scanning Marking
Specification :
1200x880x380mm
Type :
Optical Fiber Laser Marking Machine
Laser Source :
Raycus
Laser Visibility :
Visible
Trademark :
HBS
Price :
US $4,200-5,200 / P
Model NO. :
HBS-GQ-20D
Origin :
Beijing
Laser Classification :
Solid Laser
Marking Speed :
12000mm/S
Transport Package :
Cartons
Cooling :
Air Colling
Laser Wavelength :
Fiber Laser
Laser Repetition Frequency :
≤100kHz
HS Code :
8456301090
Applicable Material :
Metal
Cooling System :
Air Cooling
Production Capacity :
200/Months
Marking Area :
110*110mm
MOQ :
1 Piece
Description
Hbs-gq-20d Online Flying Laser Marking Engraving Machine
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Product Descriptions:

With the pursuit of automation, intelligent laser line processing is commonly used in many factories. The principle of flying laser marking machine is the combination of galvanometer scanning and workpiece movement in the assembly line formed by the laser marking system, which is called the flight marking system.

The flying laser marking machine improves the efficiency of industry. Many factories have achieved automated production by using flying laser marking machine.

It has been widely used in food packaging, ci-garette lot number, mineral water production date, serial number, etc.

Exhibition:
Hbs-Gq-20d Online Flying Laser Marking Engraving Machine Hbs-Gq-20d Online Flying Laser Marking Engraving Machine Hbs-Gq-20d Online Flying Laser Marking Engraving Machine Hbs-Gq-20d Online Flying Laser Marking Engraving Machine Hbs-Gq-20d Online Flying Laser Marking Engraving Machine
Detailed Technical Information
Machine Model HBS-GQ-20D
Laser Source Raycus Advanced+
Average power 30 watts
Laser Power Lifetime 100,000 hours (Theoretical data)
Fiber cable length 2.5m
Cooling Air cooling
Marking Wavelength 1064nm
Beam Quality <1.5
Laser Repetition Frequency ≤100kHz
Marking Depth 0-1.5mm (adjustable with power setting, speed, materials)
Marking Speed ≤12000mm/s
Minimum Line Width 0.01mm
Minimum Character Size 0.05mm
Repetition Precision ±0.001mm
Standard Marking Area(mm) 110*110
Optional Marking Area(mm) 75*75, 150*150, 160*160, 175*175, 200*200, 300*300
Focal Length Depends on marking area requirements
Power Consumption ≤500W
Machine Requirements AC220V(±10%), 50Hz(±10%), 10A
Operation Temperature -10ºC-60ºC
Humidity 5-95%
Control System Win7, Win8, Win10, Win XP,
RAM 2GB-16GB
HDD 500G
Marking Formats AI., PLT., DXF., TIFF., PNG., BMP., JPG. etc.
Computer Connection 2.0USB
Software Ezcad 2.9.0
Optional Lens
Lens Type HBS-65 HBS-110(Standard) HBS-175
Focal Length 100mm 170mm 250mm
Marking Area 65mm*65mm 110mm*110mm 175mm*175mm
Note: HBS will provide lens with model HBS-200 for your company, marking area: 110mm*110mm
Packaging Details:

Package: 1200x880x380 mm

Company Info:

Beijing HBS Science & Technology Development Co., LTD is founded in 2001. HBS is specialized in developing and manufacturing laser marking machine with perfect quality and excellent after-sales services.

HBS had provided numerous well-known companies with wide range of solutions and reliable marking equipment, with strong and sustainable traceability.
