Specifications
Place of Origin :
Hubei, China
Brand Name :
CHUANCHU
Model Number :
HT.RKG808-580
Working Voltage :
/
Flow Rate :
/
Warranty :
12 Months
Certificate :
/
Type :
Standard
Product Name :
manhole cover
Suit for :
Tanker Truck or Trailers
Material :
carbon steel
Max Pressure :
0.65Mpa
Function :
Protect against rupture and explosions
Power :
Manual
Medium :
Light Fuel
Customized Support :
ODM,OEM,OBM
Package :
Carton
MOQ :
1
Use :
Oil
Application :
Tanker Truck
Price :
$120/sets 1-9 sets
Packaging Details :
Wooden box
Delivery Time :
7-30 days
Payment Terms :
T/T
MOQ :
1
Supply Ability :
Meet large-scale orders
Description
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
Products Description
Manhole covers are an essential component that form part of the wider tank truck range. They act as an emergency vent for fuel tanks, but also feature several other key benefits to keep people safe in the event of an accident. These include tank breathing and flanges for ancillary equipment that help protect against rupture, division reversal and explosions. We have manufactured manhole covers for petroleum tankers for over 18 years. Manhole covers are arguably the most important safety component fitted to a vehicle's tanker. HUATE models include emergency venting to prevent tank explosion if a fire occurs (7000 m³/hr at 350 mb), as well as a pressure vacuum breather to complete with rollover seal to stop leakages if a tank is overturned. Operators are also kept safe by a two-stage opening mechanism that releases residual pressure before fully opening. This stops dangerous kick-backs. Our cast option includes blind bolt holes to ensure no liquid cargo can leak through and webs on the underside of the base plate to increase structural integrity. The springs used for the emergency venting are corrosion-proof, assuring correct operation regardless of environment.
Product Name
Fuel Tanker Truck Manhole Cap
Model
HT.RKG808-580
Whole Diameter
16 Inch
Applicable media
Light Fuel
Max Working Pressure
0.65Mpa
Max Emergency Flow Rate
7000 CBM/H
Material
Carbon steel
Installment Mode
Flanged Type
Temperature Range
-20℃~ +70℃
Open Mode
Manual
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
Max Pressure 0.65Mpa Carbon Steel Manhole Cover DN460MM European Standard Function Protect against Rupture and Explosions
ABOUT US
Hubei Huate Special Equipment Co., Ltd. is a multi-national global brand with more than 15 years of experience in manufacturing Tank Truck,Sanitation Truck,Refrigerated truck and related parts. Since the new factory was put into operation in 2017, Huate has adopted the organizational structure of flat management, relying on advanced manufacturing equipment and quality control means to further improve its design , R & D ability, manufacturing level and quality control ability. As a result of continuous R&D and customer focus, Huate develops and manufactures country-specific Special Vehicle products that become the pride of the regions where it is located. Huate aim to provide global customers with the most Comprehensive, Extensive and Stable products. Bring more refined and professional products, Better service.
