Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Pickling White Special Metals Nickel Alloy Round Bar DIN 17750 DIN 2.4360 Monel 400 Rods
Specifications
Brand Name :
HT
Model Number :
Monel 400
Certification :
ISO/SGS
Place of Origin :
China
MOQ :
100kg
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10000tons/month
Delivery Time :
30-50days
Packaging Details :
wooden/woven/ad per customer
Product Name :
Monel 400 bar
Material :
ASTM B164 UNS N04400 Alloy 400 Monel 400
Diameter :
5-300mm
Length :
1-12m
Surface treatment :
black surface
Technology :
hot rolled
Grade :
ASTM B164
Tolerance :
H7 H9 H10 H11
MOQ :
100kg
Package :
Wooden/Woven/as per customer
Description

A nickel-copper grade, Alloy 400 combines high strength and corrosion resistance.

Superb corrosion resistance in a wide range of media including seawater, hydroflouric acid, fluorine, sulphuric acid and alkalis.

CHEMICAL ANALYSIS

% C Si Mn S Fe Ni Cu
Min 0 0 0 0 0 63 28
Max 0.3 0.5 2 0.024 2.5 70 34

ABOUT ALLOY 400

Alloy 400 from HT pipe has superb corrosion resistance, particularly in neutral and alkaline salts. It is also one of a limited number of alloys that can be used in conjunction with hydrofluoric acid and fluorine. With high nickel content, this alloy is immune to chloride-induced stress corrosion cracking. The alloy also has good mechanical properties from sub-zero temperatures up to 549°C.

This alloy also performs excellently in seawater, with improved resistance to cavitation corrosion compared with other copper-base alloys. It’s often used to handle sulphuric acid up to 80% concentration at room temperature and up to 15% sulphuric acid at boiling temperatures.

PROPERTIES

Density:

8.80 g/cm³

Melting Range:

1300 - 1350 °C

Hardness:

60-80 HRB

Specific Heat Capacity:

427 J/kg.°C

Electrical Resistivity:

0.511 µΩ.m

Curie Temperature:

21-49°C

Poisson's Transus:

0.32

MECHANICAL & PHYSICAL PROPERTIES

Mechanical & Physical Properties -180°C -130°C -70°C 21.1°C 93.3°C 204.4°C 315.6 371.1°C
Ultimate Tensile Strength /MPa - - - 450 420 390 380 370
0.2% Yield Strength /MPa - - - 175 150 135 130 130
Reduction of area % - - - - - - - -
Elongation % - - - 51 44 43 47 -
Coefficient of Thermal Expansion /µm/m°C 11.1 11.4 12.1 - 14.2 15.2 15.7 16.1
Thermal Conductivity /kcal/(hr.m.°C) 14.19 15.65 17.03 18.92 20.64 23.13 25.89 28.72
