ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap
ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap
ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap
ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap
Specifications
Brand Name :
HT
Model Number :
ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap
Certification :
PED SGS ISO TUV
Place of Origin :
China
MOQ :
50KG
Price :
USD 9 PIECE
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000KG PER MONTH
Delivery Time :
15-20
Packaging Details :
wooden case packing
Material :
ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap
Name :
elbow tee stud end cap
Size :
1/2"-48"
Type :
Buttweld
Description

ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap

ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap

ASME 16.9 Low Alloy Steel ASTM A234 WP91 WP11 WP22 WP9 Elbow Tee Bend Cap

ASTM A234 WP11 pipe fittings mean the pipe fittings which material are ASTM A234 WP11,they are used for the pressure piping systems of moderate and high temperature services.ASTM A234 is the standard of butt welding P pipe fitting, it indicates the materials properties of different kinds of carbon steel and alloy steel,WP11 is one of the steel grade in this standard.

Type of the ASTM A234 WP11 steel pipe fittings:

The regular products of ASTM A234 WP11 pipe fittings are elbows,tees,reducers,caps,cross,bends,laterals etc.There are seamless and welded A234 WP11 pipe fittings,the seamless A234 WP11 pipe fittings means the fittings are made from the seamless steel pipes,welded WP11 pipe fitting means it is made from welded pipes and steel plates.

Chemical Composition (%) of ASTM A234 WP11:

Grade C Mn P S Si Cr Mo
WP11 Class1 0.05-0.15 0.3-0.6 ≤0.03 ≤0.03 0.5-1 1-1.5 0.44-0.65
WP11 Class2 0.05-0.2 0.3-0.8 ≤0.04 ≤0.04 0.5-1 1-1.5 0.44-0.65
WP11 Class3 _ _ _ _ _ _ _

Mechanical properties of ASTM A234 WP11:

Item Tensile Strength KSI(MPa) Yield Strength KSI(MPa)
WP11 Class1 60-85(415-585) ≥30(205)
WP11 Class2 70-95(485-655) ≥40(275)
WP11 Class3 75-100(520-690) ≥45(310)

ASTM A234 ALLOY STEEL BUTTWELD ELBOW, WP22 SEAMLESS BUTT WELD FITTINGS EXPORTER, ALLOY STEEL WP22 EQUAL CROSS, WP22 LONG RADIUS BEND, AS WP22 PIPE FITTINGS SUPPLIER.

ASTM A234 WP22 PIPE FITTINGS CHEMICAL COMPOSITION

Grade C Mn P S Si Cr Mo
A234 WP22 0.05-0.15 0.3-0.6 ≤0.04 ≤0.04 ≤0.5 2-2.5 0.87-1.13

ASTM A234 WP22 PIPE FITTINGS MECHANICAL PROPERTIES

Element Tensile Strength Yield Strength (0.2%Offset) Elongation
A234 WP22 415-585 ≥205 ≥20
