Specifications
Brand Name :
HanWei
Model Number :
HW-DH-ECO-MP
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
USD / Set
Payment Terms :
T/T
Supply Ability :
2000 Sets / year
Delivery Time :
10 working days
Packaging Details :
Export Plywood Packing
Laser Power :
Up to 6000W
Electrical Input Voltage :
380v 50Hz / 60Hz
Welding Materials :
Aluminium / Copper / Stainless Steel / Brass / Gold / Silver
Laser Beam :
Ring and Spot
Power Consumption :
≤ 30 KW
Cooling Method :
Water Cooling
Laser Core :
50 um/ 60um
Laser power stability :
≤ 3%
Laser Power adjustable :
10~100%
Laser output frequency :
≤ 20 Khz
Description

RS Series Ring and Spot High-Quality Laser Welder for Various Metals & Thicknesses


RS Series Ring and Spot High-Quality Laser Welder for Various Metals & Thicknesses Description:


Launched in 2020, HW-AMB-ECO laser welding solution represents a patented breakthrough developed through independent research. Unlike conventional ring-spot laser sources widely used in the global market, this system follows a distinct technical architecture designed to optimize beam structure and energy interaction. This differentiated approach enables strong industrial performance while maintaining outstanding cost efficiency, making it a strategic investment for manufacturers seeking advanced laser solutions without excessive capital expenditure.

The machine integrates a specially engineered circular beam configuration that enhances molten pool dynamics and stabilizes the welding process. By improving energy distribution within the weld zone, the system significantly reduces metal splash and minimizes post-processing requirements. The optimized thermal profile also supports higher travel speeds, improving productivity in automated production lines and continuous fabrication environments.

RS Series Ring and Spot High-Quality Laser Welder for Various Metals & Thicknesses Features:


1. Advanced Circular Beam Engineering for Cleaner and Faster Welding.

2. Intelligent Laser Control Platform for Multi-Material Versatility.

3. Optimized Performance for Aluminum, Copper and Stainless Steel.

4. More Throughput - Increased productivity - maximizes uptime and significantly reduces rework of welded parts.

5. Lower operating costs - benefit from lower machine down-times, less post-processing, fewer rejects and very high protective glass resistance.

6. Maximum application flexibility.

7. Easy to operate and maintenance.

8. Touch screen - digital parameter setting in monitor.

9. Language in English as standard. (Support Customized Language in Controller)

10. Laser beam size adjustable 0~5mm according to welding requirements.

11. Inside of laser head with simple structure and high sealing performance.

12. Extremely durable lens.Drawer type mirror holder - Easy for replacing.

13. High performance laser welding head with laser source and controller.

14. Suitable for various automation supporting solutions.

15. Competitive Quotation.



RS Series Ring and Spot High-Quality Laser Welder for Various Metals & Thicknesses Technical Parameters:


Model HW-DH-ECO-MP
Laser Power 4000 W / 6000 W
Laser Source HW-DH-Middle Power / HW-DH-High Power
Laser Beam Ring and Spot
Laser Core 50um / 100um

Laser Power Stability

 ≤ 3%
Laser Power adjustable 10%~100%
Laser output frequency ≤ 20 Khz
Cooling Method Water Cooling
Controller system HW-AMB
Laser Head HW-AMB-36
Camera and Monitor Welding process
X axis travel Option
Y axis travel Option
Z axis travel Option
Rotary axis travel Option
Working mode CW / QCW / PWM
Mechanical Software HW Laser
Display screen HW Laser
Machine Size 875*531*849mm
Machine Weight 150 Kg / 200 Kg
Ambient Temperature 5~40℃
Ambient Humidity 30%RH~70%RH
Rated Input Voltage 380v 50/60Hz
Power Consumption ≤ 20Kw / ≤ 30Kw


RS Series Ring and Spot High-Quality Laser Welder for Various Metals & Thicknesses Application:


Equipped with a proprietary laser management platform, HW-AMB-ECO laser welding technology allows precise adjustment of output parameters to accommodate diverse materials and thickness ranges. Whether processing thin precision components or thicker structural assemblies, the machine maintains consistent penetration depth and mechanical strength. This flexibility supports applications across industries such as new energy systems, metal fabrication, industrial equipment manufacturing, and electronic enclosures.


The Starship Fiber Laser Welding Machine is specifically engineered to handle challenging materials including aluminum and copper, ensuring stable weld formation with minimal surface contamination. Stainless steel welding achieves smooth bead appearance and structural reliability. The system’s material adaptability reduces production variability and enhances overall manufacturing efficiency in high-standard industrial environments.


RS Series Ring and Spot High-Quality Laser Welder for Various Metals & Thicknesses Sample:

Copper
Aluminum
Steel


Shen Zhen HanWei Laser Enterprise and Feature:

Shenzhen Hanwei Laser Equipment Co., Ltd. offers a comprehensive range of laser equipment, including desktop and portable models. These systems adopt advanced fiber laser, pulsed or continuous-wave, blue laser, diode laser and hybrid laser technologies, carefully engineered to meet the unique requirements of customers. In addition, the company provides customized solutions for specific applications, as well as professional training and support services, enabling customers to fully maximize the performance of their laser systems. With branches and subsidiaries across Europe, North America, Asia and the Middle East, Hanwei Laser has established a strong global presence to serve customers around the world.

Hanwei Laser maintains a core focus on the laser welding sector. The company is committed to providing state-of-the-art laser welding technologies to international laser integration enterprises. Its mission is to deliver high-quality welding solutions to integrators worldwide. As one of the few global enterprises certified as a national high-tech and specialized, sophisticated, distinctive and innovative enterprise, it specializes in the full-industry-chain R&D, manufacturing and sales of various welding lasers, laser control systems, laser optical systems and laser welding processes.
