HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
Specifications
Brand Name :
HanWei
Model Number :
HW-Y-8/25/80/160/300/500
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
USD / Set
Payment Terms :
T/T
Supply Ability :
2000 Sets / year
Delivery Time :
10 working days
Packaging Details :
Export Plywood Packing
Model :
HW-Y-8/25/80/160/300/500
Input Electric :
AC220 50/60 Hz / AC380 50/60 Hz
Output Power :
8/25/80/160/300/500W
Weight :
100/170/180/220/240 Kg
Dimension :
955*415*870 mm/ 1175mm×515mm×980mm/ 1360mm×630mm×1120mm
Cooling mode :
Air / Water
Power Stability :
± 2.5 / ± 3.0
Pulse width :
15 ms
Frequency :
30/100 Hz
Working Mode :
Pulse
Pulse Energy :
5J /25J /50J / 70/100J
Equipmen :
1/1.2/3/6/12/16 Kw
Wavelength :
1064nm
Description
HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
The platform galvo swing welding head features a compact size and lightweight design, making it ideal for integration into industrial automated production lines. The lightweight structure reduces the motion load on robotic arms or platforms, while enhancing response speed and welding accuracy, enabling more efficient high-intensity, multi-station production.
Key Features
  • Compact & Lightweight for Improved Automation Efficiency.
  • Multi-Trajectory & Flexible Beam Adjustment.
  • Wide Application Across Multiple Industries.
  • Easy Maintenance & Low-Cost Design.
  • Stable & Reliable Laser Control System.
Technical Specifications
Model HW-PT-36 HW-PT-50
Usable Power 3000 W maximum 6000 W maximum
Collimating length 100 100
Focus length 200 / 250 / 300 / 350 200 / 250 / 300 / 350
Interface type QBH QBH
Accessible wave range 1064 nm 1064nm
Head Type Customized Customized
Net weight 2.3 kg 3.5 kg
Beam size adjustable 0.5 – 5mm 0.5 – 5mm
Laser beam mode ―,○,◎,⊙,△,8 ―,○,◎,⊙,△,8
Usable laser source Most of laser source Most of laser source
Applications
The focusing and collimating lenses adopt a drawer-type installation for quick disassembly and assembly. Maintenance or replacement can be completed without prolonged downtime, reducing daily maintenance costs, improving equipment availability, and keeping production lines running smoothly.

Equipped with a mature laser control system that has undergone years of optimization, the welding head offers high stability and strong anti-interference capability. Whether for long-term continuous welding or high-precision micro-welding, the system ensures stable spot output and achieves high-quality, highly consistent laser welding results.
About Shenzhen Hanwei Laser
Hanwei Laser upholds the philosophy of "R&D as the core driving force, technology as the solid foundation, and service as the key support", providing customized professional solutions for B2B clients including laser equipment manufacturers, automation enterprises, and other related sectors. Its service commitments center on reliable product quality, steady technological progress, sustained innovation, and comprehensive after-sales support.

Backed by profound expertise in laser technology, system integration, power supply configuration, control system R&D, optical structure design, and welding process optimization, Hanwei Laser’s technical team draws on solid theoretical knowledge and extensive practical experience to deliver efficient, high-performance solutions tailored for a wide range of industrial applications.

The company’s product range features an independently developed optical system architecture, paired with scientifically optimized optical path design and high energy transmission efficiency. Core optical components adopt high-quality imported quartz optical lenses, integrated with cutting-edge international coating technologies, achieving industry-leading performance in reflectivity, light transmittance, and thermal stability.

This sophisticated design not only guarantees the stability of laser energy delivery but also effectively prolongs the service life of the system and enhances the consistency of processing results.

Hanwei Laser’s products are widely applied across numerous industries, including new energy batteries, automotive manufacturing, auto parts, electronic circuits, fiber-optic communication equipment, consumer electronics, home appliances, kitchen and bathroom hardware, precision instruments, measuring tools, jewelry processing, medical devices, solar energy, eyewear manufacturing, and motor production.HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment HanWei Platform Galvanometer Wobble Welding Head with Flexible Beam Adjustment
