Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Specifications
Brand Name :
HanWei
Model Number :
HW-Y-8/25/80/160/300/500
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1 Set
Price :
USD / Set
Payment Terms :
T/T
Supply Ability :
2000 Sets / year
Delivery Time :
10 working days
Packaging Details :
Export Plywood Packing
Model :
HW-Y-8/25/80/160/300/500
Input Electric :
AC220 50/60 Hz / AC380 50/60 Hz
Weight :
100/170/180/220/240 Kg
Wavelength :
1064nm
Cooling mode :
Air / Water
Power Stability :
± 2.5 / ± 3.0
Pulse width :
15 ms
Frequency :
30/100 Hz
Working Mode :
Pulse
Dimension :
955*415*870 mm/ 1175mm×515mm×980mm/ 1360mm×630mm×1120mm
Pulse Energy :
5J /25J /50J / 70/100J
Equipmen :
1/1.2/3/6/12/16 Kw
Output Power :
8/25/80/160/300/500W
Description
Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
Adopting a highly integrated design concept, the platform galvanometer scanning welding head optimally arranges the galvanometer system and optical components for a more compact overall structure. With a lighter self-weight, it can effectively reduce the motion load of the gantry, minimize mechanical wear during long-term operation, and lay a stable foundation for high-beat automated welding.
Key Features
  • Advantages of Compact Body and Low Load.
  • Highly Programmable Oscillation and Beam Control.
  • Application Capability for Complex Working Conditions.
  • Optimal Optical Structure Design for Quick Maintenance.
  • Time-Tested Control System Platform.
Technical Specifications
Model HW-PT-36 HW-PT-50
Usable Power 3000 W maximum 6000 W maximum
Collimating length 100 100
Focus length 200 / 250 / 300 / 350 200 / 250 / 300 / 350
Interface type QBH QBH
Accessible wave range 1064 nm 1064nm
Head Type Customized Customized
Net weight 2.3 kg 3.5 kg
Beam size adjustable 0.5 – 5mm 0.5 – 5mm
Laser beam mode ―,○,◎,⊙,△,8 ―,○,◎,⊙,△,8
Usable laser source Most of laser source Most of laser source
Applications
The focusing lens and collimating lens inside the welding head adopt a draw-out modular structure, eliminating the need for overall disassembly of the welding head during maintenance. This design enables more efficient replacement of optical components, cuts labor and time costs, helps alleviate after-sales maintenance pressure, and enhances the long-term use value of the equipment.
The supporting laser control system has been continuously upgraded based on years of application experience, boasting excellent system response speed and anti-interference performance. Even in complex electromagnetic environments or under long-term operation conditions, it can maintain the stability of oscillation control and laser output, providing a reliable guarantee for high-quality welding.
About Shenzhen Hanwei Laser
Hanwei Laser adheres to the principle of "taking R&D as the core impetus, technology as the firm cornerstone, and service as the pivotal support", offering tailor-made professional solutions for B2B customers covering laser equipment manufacturers, automation enterprises and other relevant fields. Its service pledges focus on dependable product quality, continuous technological advancement, persistent innovation capacity, and comprehensive after-sales assistance. Endowed with profound proficiency in laser technology, laser system integration, power supply deployment, control system research and development, optical structure design, and welding process refinement, Hanwei Laser’s technical team leverages solid theoretical foundations and rich practical experience to provide efficient, high-performance solutions customized for diverse industrial scenarios.

The company’s product lineup boasts an independently developed optical system framework, combined with a scientifically optimized optical path configuration and high energy transmission efficiency. Core optical components are made of high-grade imported quartz optical lenses and integrated with advanced overseas coating technologies, reaching industry-leading levels in terms of reflectivity, light transmittance, and heat resistance. This elaborate design not only ensures the stability of laser energy transmission but also effectively extends the system’s service life while improving the consistency of processing outcomes. Hanwei Laser’s product range is extensively utilized in a wide array of industries, such as new energy batteries, automotive manufacturing, auto parts, electronic circuits, optical fiber communication equipment, mobile electronics, home appliances, kitchen and bathroom hardware, precision instruments, measuring tools, jewelry processing, medical devices, solar energy, eyewear production, and motor manufacturing.
Product Portfolio
  • Mold repair laser welders
  • Ring-Spot laser welding equipment
  • Blue laser welding systems
  • Blue laser + fiber hybrid welders
  • Diode + fiber hybrid welders
  • YAG laser welders
  • YAG + Diode hybrid welders
  • Diode laser welders
  • QCW laser weldersGantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions Gantry Galvanometer Wobble Welding Head – Adaptable to Complex Working Conditions
