Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Specifications
Model Number :
HW-BFH-XXXXXX
Collimating length :
Diode 110 – Fiber 100/120/150
Payment Terms :
T/T
Focuses length :
200
Supply Ability :
2000 Sets / year
Head Type :
Y
Brand Name :
HanWei
Interface type :
QBH - QBH
Packaging Details :
Export Plywood Packing
MOQ :
1 Set
Delivery Time :
15 working days
Accessible wave range :
915nm + 1064nm
Model :
HW-BFH-XXXXXX
Price :
USD / Set
Net Weight :
2.5 Kg
Certification :
CE
Usable laser source :
Diode and Fiber laser source
Place of Origin :
Shenzhen, China
Laser Power :
Diode laser ≤ 30000 W & Fiber laser ≤ 4000 W
Description
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure

The semiconductor laser welding head is developed for semiconductor laser systems and provides a practical solution for laser-based joining applications. It is designed to work with semiconductor laser sources in processes such as medium-thickness metal plate welding, large component welding, soldering, and plastic welding. The welding head helps deliver laser energy from the source to the working area for different industrial processing requirements.

With its application-oriented design, this welding head can be used in different production environments where semiconductor laser welding is required. From metal component assembly to soldering and plastic joining processes, the product provides a flexible option for manufacturers who need a dedicated welding component for different material processing tasks.

Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure
Key Features
  • A Dedicated Welding Solution for Semiconductor Laser Sources.
  • Suitable for Various Manufacturing Processes.
  • Cost-Effective Design for Industrial Equipment Integration.
  • Multiple Interface Configurations Available.
  • Covers Semiconductor Laser Power from 30W to 4000W.
  • Integrated Water Cooling and Fully Enclosed Internal Structure.
Technical Specifications
Model

HW-36-XXXXXX-T-QBH

HW-50-XXXXXX-F-QBH
Usable Power

200 W maximum

500-4000 W maximum

Collimating length

80/100/120/150/200

100 / 150 / Customized

Focus length

80/100/120/150/200

80/100/120/150/200
Interface type

SMA 905 / D80

SMA 905 / QBH
Accessible wave range 1064 1064
Head Type

F / T / Y

F / T / Y
Net Weight

1.1 kg

2.7 kg

Usable laser source

Diode laser source

Diode laser source
Application Advantages

The semiconductor laser welding head focuses on combining practical performance with reasonable cost. It is an economical choice for users who need to build or upgrade laser welding systems while keeping equipment investment under control. The design provides a straightforward solution for integrating semiconductor laser technology into industrial applications.

Different semiconductor laser systems may require different connection methods. This welding head is available with SMA905, D80, and QBH interface options, allowing users to select a suitable configuration according to their laser source requirements. The multiple interface choices improve flexibility when matching the welding head with different equipment systems.

About Shenzhen Hanwei Laser
Founded in Shenzhen, Shenzhen Hanwei Laser Equipment Co., Ltd. specializes in the development and production of laser welding equipment and critical core laser accessories. Our business targets industrial manufacturers and laser solution integrators from all over the world. We work with customers from different markets through product consultation and technical communication, helping them understand available equipment options and select suitable solutions according to their requirements.
Semiconductor Welding Head with Integrated Cooling & Enclosed Internal Structure

By continuously following changes in laser technology and industrial manufacturing needs, Hanwei Laser provides equipment choices for businesses exploring laser processing methods in their production activities.
