Specifications
Brand Name :
Dimax
Model Number :
55 non thermal break series AwningWindow
Certification :
AS 2047
Place of Origin :
China
MOQ :
1
Price :
800-1200rmb
Payment Terms :
T/T,L/C
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Maintenance :
Low maintenance requirements
Finish :
Anodized or Powder Coated Aluminum
Soundinsulation :
Effective soundproofing
Thermalperformance :
High thermal insulation
Energyefficiency :
Supports energy saving building design
Waterproofing :
High water resistance
Installationmethod :
Unitized system with pre-assembled units
Panelsize :
Factory-assembled large panels
Description

INFORMATION

55 non thermal break series AwningWindow
System 55 non thermal broken series Fixed/Awning/Awning+ Fixed, with flyscreen/louver available
Brand DIMAX
Material 6063-T5
Certification AS2047
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux (warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,Doric and so on
Configuration A. AA. A/F or customized design
Flyscreen Fiberglass/Stainless steel available
Fixing Method Sub sill/Sub head/Finx fix/Face fix/Timber reveal available
Air Infiltration Low
Design Wind Pressure 1000pa
Water Resistance 300Pa
Ufimate Wind Pressure 2300pa
Insulative Effectiveness Configure according to the project requirements
soundlnsulafion Configure according to the project requirements

As an essential element of architectural and home design, windows not only influence the appearance of a building but also directly impact indoor comfort and energy efficiency. Among various window frame materials, aluminum stands out for its exceptional strength and durability, making it a preferred choice for modern window and door systems. We specialize in manufacturing windows and doors using extruded aluminum, delivering outstanding structural performance and long-term value to meet the demands of high-quality construction.

Compared to commonly used roll-formed aluminum, extruded aluminum profiles feature significantly greater thickness and cross-sectional strength. This difference in manufacturing not only enhances the overall sturdiness of the material but also improves its resistance to deformation and pressure, thereby substantially increasing the structural stability and durability of windows and doors. Whether under extreme weather conditions or in daily long-term use, this type of aluminum maintains excellent performance, reducing maintenance needs and extending product lifespan.

Choosing aluminum windows means opting for a low-maintenance, long-lasting solution. Aluminum is naturally corrosion-resistant and does not rust, while surface treatment technologies can further enhance its weather resistance and aesthetic appeal. Combined with thoughtful design and advanced manufacturing, aluminum windows can effectively improve a building’s thermal insulation, soundproofing, and security performance, delivering lasting value to living and working spaces.

We believe that high-quality aluminum windows are not just part of a building but a key component in connecting indoor and outdoor environments and enhancing the quality of life. Through continuous innovation and strict material selection, we are committed to providing customers with aesthetically refined, reliable, and durable window and door products—helping you create safer, more comfortable, and energy-efficient architectural spaces.
