Unmanager Single Port Ethernet Switch 10/100Mbps With 20KM Distance
Unmanager Single Port Ethernet Switch 10/100Mbps With 20KM Distance
Specifications
Brand Name :
HD
Model Number :
HD-UM-1F1E-M-SFP
Certification :
CE/RoHS/FC
Place of Origin :
CHINA
MOQ :
10 PCS
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
3-7working days after received deposit
Packaging Details :
Packed in carton
Product Name :
1*10/100Base TX to 1*100M FX single SFP port Industrial Ethernet Switch unmanager
Transmission Rate :
10/100Mbps
Transmission Distance :
20KM
Operating temperature :
-40 ~ 80°C
Input Voltage :
DC10-58V
Communication Mode: :
Full-Duplex & Half-Duplex
Switch Capacity :
2G
Recovery time :
<15ms
Description

1*10/100Base TX to 100M FX single SFP port Industrial Ethernet Switch unmanager

what's the features of our industrial switch ?

  • Comply to IEE 802.3 10Base-T,IEEE802.3u ,100Base-TX/FX
  • Provide a SC single-mode /multimode optical port and 10/100M RJ45 port, support for Full/half duplex mode and auto MDI/MDI-X connection
  • Comply to IEEE 802.3af , provide power for the IP cameras over Ethernet
  • Dynamic LED indicator, display the current operating status, providing a simple working condition and troubleshooting tips
  • Adopt IEEE 802.3x Standard full-duplex flow control ,with standard duplex Backpressure flow control

what's the Description of our industrial switch ?

1, Wide Operate Temperature : -45°C~80 °C

2, PoE (PSE) IEEE802.3af /at Compliant

3, Redundant dual power input booster : 48V DC (46~50VDC)

4, industrial grade EMS certified

5, Support OP-Ring, proprietary technology ( patent Protocol )

6, OP-Ring protection and recovery within 15ms

7, IP 40 Protection grade housing protection

8, Full /Half duplex mode

9, DIN-Rail and Wall Mounting Installation ,flexible and convenient

10, Web-based,CLI management(Unmanagement optional)

what's the Specification of our industrial switch ?

Standards: IEEE802.1 10Base-T,
IEEE802.3u 100Base-TX,
IEEE802.3 100Base-FX		 Input Voltage:

Input Voltage: 48V DC

(46~50VDC)
Redundant power input
Overload Current Protection
Support dual power backup
Support dual power alarm input
Connection: 6 pin terminal
RJ45 port rate:

10/100BaseT(X) auto connection,

Full /Half duplex or force work mode,

and support MDI/MDI-X connection
Fiber Ports:

100BaseFX ports

(SC/ST/FC/LC connector, optional)

 Casing: IP40 protection, Aluminium Alloy
Multi-mode: 2,5Km,optional Instanation: DIN-Rail or wall mounting

Wavelength

Input Voltage

 850nm, 1310 nm, 1550nm EMI

FCC Part 15, CISPR (EN55022)

class A
48V DC(46~50VDC)
Typical 100Base-FX 155Mbps, 1310nm, 2Km,
average output≥-18dBm,
sensitivity≤-35dBm		 EMS: EN61000-4-2 (ESD),Level 3
EN61000-4-3 (RS),Level 3
EN61000-4-4 (EFT),Level 3
Single-mode:155Mbps, 1310nm, 20Km,
average output≥-12dBm,
sensitivity≤-36dBm		 EN61000-4-5 (Surge),Level 3
EN61000-4-6 (CS),Level 3
EN61000-4-8,Level 3
Warranty 3 year Shock: IEC 60068-2-27 PASS
Dimensions: 60.5 x 118 x 140mm Free Fall IEC 60068-2-32 PASS
Weight: 720g Vibration:

IEC 60068-2-6 PASS
