40km CWDM SFP Fiber Transceiver , 10 100 1000mbase Single Mode SFP Module
40km CWDM SFP Fiber Transceiver , 10 100 1000mbase Single Mode SFP Module
Specifications
Brand Name :
HD
Model Number :
HD-S8512-1LCD
Certification :
CE/RoHs/FCC
Place of Origin :
CHINA
MOQ :
1 PC
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
50000 pcs per month
Delivery Time :
3-7working days after received deposit
Packaging Details :
Packed in carton
Product Name :
Fiber optic equipment 1270-1610nm channel SFP Fiber transceiver 1.25gbps sfp cwdm 40km
Rate :
10/100/1000m
Customized :
Free logo
Wavelength: :
1270-1610nm
DDM/DOM :
Yes
Fiber Type: :
BIDI
Description

1.25Gbps 1290nm/1350nm 40km CWDM BiDi SFP LC

Product Features

  • 1.25Gbps Data transfer rate
  • Simplex LC Conector
  • Tx1290nm/Rx1350nm and Tx1350nm/Rx1290nm CWDM BiDi SFP (60nm Spacing)
  • CWDM Laser Transmitter and PIN Receiver
  • Distance up to 40km
  • Single 3.3V Power Supply and TTL Logic Interface
  • Hot-Pluggable SFP
  • Compliant with SFP MSA and SFF-8472
  • Digital Diagnostic Monitoring
  • Operating Case Temperature: 0-70℃


Applications

  • Gigabit Ethernet
  • Fiber Channel
  • CWDM BiDi Mux Systems
  • Switch to Switch interface
  • Switched backplane applications
  • Router/Server interface
  • Other optical transmission systems

Pin Descriptions

Pin Symbol Name/Description Ref.
1 VeeT Transmitter Ground (Common with Receiver Ground) 1
2 TX Fault Transmitter Fault.
3 TX Disable Transmitter Disable. Laser output disabled on high or open. 2
4 MOD_DEF(2) Module Definition 2. Data line for Serial ID. 3
5 MOD_DEF(1) Module Definition 1. Clock line for Serial ID. 3
6 MOD_DEF(0) Module Definition 0. Grounded within the module. 3
7 Rate Select No connection required
8 LOS Loss of Signal indication. Logic 0 indicates normal operation. 4
9 VeeR Receiver Ground (Common with Transmitter Ground) 1
10 VeeR Receiver Ground (Common with Transmitter Ground) 1
11 VeeR Receiver Ground (Common with Transmitter Ground) 1
12 RD- Receiver Inverted DATA out. AC Coupled
13 RD+ Receiver Non-inverted DATA out. AC Coupled
14 VeeR Receiver Ground (Common with Transmitter Ground) 1
15 VccR Receiver Power Supply
16 VccT Transmitter Power Supply
17 VeeT Transmitter Ground (Common with Receiver Ground) 1
18 TD+ Transmitter Non-Inverted DATA in. AC Coupled.
19 TD- Transmitter Inverted DATA in. AC Coupled.
20 VeeT Transmitter Ground (Common with Receiver Ground) 1



Order information

Type Part Number Data Rate Wavelenth(nm) Distance
CWDM SFP CWDM-OC3-80 155M 1270-1610 80km
CWDM-OC3-120 155M 1270-1610 120km
CWDM-OC3-150 155M 1270-1610 150km
CWDM-OC24-80 1.25G 1270-1610 80km
CWDM-OC24-120 1.25G 1270-1610 120km
CWDM-OC48-40 2.5G 1270-1610 40km
CWDM-OC48-80 2.5G 1270-1610 80km

1.25Gbps 1290nm/1350nm 40km CWDM BiDi SFP LC
