HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery
HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery
HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery
HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery
HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery
HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery
Specifications
Brand Name :
HAINA
Model Number :
HNJX-UNK600
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
72 SETS/YEAR
Delivery Time :
150 Days
Packaging Details :
Film wrapped
Design Speed :
600 PPM
Stable Production Speed :
400 / 500 / 550 PPM
Rejection Rate :
≤3%
Power Source :
380V, 50HZ
Air Pressure :
0.6 - 0.8 Mpa
Product Structure :
Fluff Type
Warranty :
One Year
Condition :
New
Description

Customized Full Servo Baby Diaper Machinery I Shape Mitsubishi PLC

Item Raw materials
1 Hydrophilic NW (Topsheet)
2 Hydrophobic NW (Legcuff)
3 Elastic for Legcuff
4 ADL
5 Fluff pulp
6 SAP
7 Upper tissue/NW
8 Lower tissue/NW
9 PE film
10 NW for laminating
11 Frontal tape
12 NW for S cut
13 Hook for S cut
14 Glue for S cut
15 NW for big waistband
16 Elastic for big waistband
17 Construction glue
18 Elastic glue
19 Wetness indicator glue

HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery

HAINA HMI Touch Screen Auto Pack 0.6Mpa Baby Diaper Machinery

Process:

1. The machine can produce four sizes (NB / S / M / L/ XL / XXL) baby products by changing cutting tools and gear box

2. High speed teeth-like crusher can take treated and untread pulp.

3. Full servo control machine is totally driven by servo motors without shafts transmission.

4. Mitsubishi/Siemens PLC centralized control

5. Automatic splicing material without stopping the machine, so the working speed is guaranteed.

6. Automatically detect and reject defective products and trim remove.

7. Automatically stop the machine when material is broken or used out.

8. Human machine interface is controlled by touch screen.

9. Safety protective door.

10. All electric components are famous international brand.

11. All cutter assembly & machine body are CNC processing

12. In the frontal and back side of the machine, there is emergency stop line which is able to stop the machine at any place in emergency.

Machine System:

  • Program System

Servo driven, intelligent HMI touch screen man-machine interface

  • Tension System

Tension control with buffer system, automatic web guiding system, to ensure materials stable working at zero speed splice.

  • Driven System

Servo drive, digital size change, ensure run synchronously at full process.

  • Driven System

Servo drive, digital size change, ensure run synchronously at full process.

  • Safety System

Safety guard for operating side, emergency stop switch, security identifier, safety pull wire at driven side.

  • Auto Pack System

Auto stacker and Packaging machine to be defined by customer need.

  • Web Guiding System

BST , Germany / FIFE, USA

  • Customized Function Available

Introduction

Jinjiang Haina Machinery Co., Ltd is a very professional equipment manufacturer in China. Specializing in baby-diapers, adult-diapers, sanitary napkins machinery. With the spirit of keeping innovating and improving, Haina has made more achievements and earned very good reputation in this field during these years. Haina was listed on Hongkong exchange stock market successfully on June this year.(Stock code HK1645).

About Haina Machinery history:

1. Jan. 2011, Haina was founded in Jinjiang City, Fujian Province.
2. Nov. 2011, Haina started R&D for the class pull-up baby diaper line.
3. Jun. 2012, We finished production of class pull-up baby diaper line.
4. Mar. 2013, Finished production of our full surrounded baby diaper line.
5. Sept. 2013, Recognized as National level high-new technology enterprise.
6. Nov. 2013, We got CE certificate.
7. Dec. 2014, R&D and finished production of new type pull-up line.
8. Feb. 2014, U-type hourglass baby diaper productione line was delivered.
9. Dec. 2015, Adult pants production line was delivered.
10. Jul. 2016, Sold machines to Hengan Group-No.1 hygiene factory in China.
11. Apr. 2016, HANGZHOU HAINA (second branch) set up.
12. Jun. 2020, Haina is successful to list on HongKong Stock exchange market.
