Pulp Molding 0.8Mpa 700pcs/Min Diaper Manufacturing Plant
Pulp Molding 0.8Mpa 700pcs/Min Diaper Manufacturing Plant
Specifications
Brand Name :
HAINA
Model Number :
LK800
Certification :
ISO9001:2015
Place of Origin :
JINJIANG, CHINA
MOQ :
1SET
Price :
Negotiatable
Supply Ability :
70 Machines Per Year
Delivery Time :
6 Months After Receiving Deposit and Confirm Product Drawing
Packaging Details :
Seaworthy Packing
Condition :
New
Product Type :
Pant Type
Power :
400KW
Voltage :
380V, 50HZ
Certificate :
ISO,CE
Warranty :
1 year
Design Speed :
800ppm
Stable Working Speed :
700ppm
Description

High Performance 700ppm Baby Diaper Machine For Training Pants

Main Features:

1. Full-servo auto-controlling system with high automation while the machine can be also upgraded as per customers’ reasonable requirement.

2. Under European CE standard designing, passed the CE certificate, electric parts under CE or UL quality certification, with safety protection unit, such as, safety door and emergency stop and so on.

3. Most of the spare parts are under numerical control precisely processing, key mechanical pars are under CNC processing, main outsourcing parts are of world famous brand.

4. Operating interface is the industry PLC with humanistic designing and optional collection for production record.

5. It is workable to mount the camera monitoring system, which can conduct on-line size checking, location inspecting, missing inspecting, stain spot scanning and so on.

6. Other optional functions can be chosen by customers’ requirement:

7. Jumbo roll auto splicing servo control b. Jumbo roll auto splicing converter control c. Jumbo roll semi-automatic unwinding d. Full-servo control stacker(Auto Bagging Machine) e. Automatic bagging sealing machine.

Configuration:

Products M/L/XL/XXL Baby Pants diapers
Products Structure and Dimension The final products drawing to be confirm by both parties
Material components for fluff base Top sheet NW, Cuff NW. AQL, Upper tissue/Nonwoven, Fluff+ SAP, Down tissue, Lamination NW., Inner Waist NW., Outer Waist NW., Picture tape, Waist Elastics,Disposable tape, Leg & Cuff elastic.
Design speed 800PPM(Size M)
Production speed 700PPM (size M)
The production speed is related to the machine configuration, product structure, raw materials quality and operator level
Defective rate ≤3%(Excluded the defectives from raw materials, glue applicators and splicing reasons)
Efficiency ≥85%
Power Supply 3 Phase 380V AC, 50HZ 3ph + N
Control Power Supply 24V DC
Power 450KW (Final confirmation according to the machine design)
Required Air Compressor 5m³/min,0.6-0.8Mpa
(Air source supplied by the Customer)
