8040-HD Medical Needle Tip Strength and Piercing Force Tester
8040-HD Medical Needle Tip Strength and Piercing Force Tester
8040-HD Medical Needle Tip Strength and Piercing Force Tester
8040-HD Medical Needle Tip Strength and Piercing Force Tester
8040-HD Medical Needle Tip Strength and Piercing Force Tester
8040-HD Medical Needle Tip Strength and Piercing Force Tester
Specifications
Brand Name :
HAIDA
Model Number :
8040-HD
Certification :
CE,ISO
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash,escrow
Supply Ability :
30 Sets per Month Haida
Delivery Time :
20 days after order confirmed
Packaging Details :
ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Power :
Electronic
Range :
0 ~ 1000g
Test speed :
1 ~ 40mm/s, arbitrary settings
Dimensions :
500 x 400 x 600 mm
source :
220V, 50Hz
Printing system :
embedded thermal printer
Description
8040-HD Medical Needle Tip Strength and Piercing Force Tester
8040-HD Medical Needle Tip Strength and Piercing Force Tester
Product Features

Medical Needle Tip Strength and Piercing Force Tester is used to test the puncture force performance of the syringe tip, evaluate whether the sharpness of the syringe meets the standard requirements, and is also known as the Syringe puncture force tester.

TECHNICAL PARAMETERS
Feature Description
Product Features
Display 7-inch K600+ core / dot matrix 65-color, 800*480 resolution touch screen, dynamically displays loading force value via PLC control system.
User Interface Selectable: Chinese / English / Chinese-English switchable.
Control & Data Acquisition Digital closed-loop control, AD sampling speed of 500KHz, internal resolution of 500,000.
Data & Protection High-precision clock chip, power-off storage; Overload alarm and automatic shutdown protection.
Touch Controls Nominal specification, Test item, Applied load, Print, Test, Up, Down, Time, Calibration.
Printing Built-in printer outputs test results.
Standards & Testing
Execution Standard Designed and manufactured per standard "YY0043-2016" (Medical Suture Needles).
Test Items Strength, Puncture Force.
Specifications
Nominal Specification 0.2 ~ 2.4 mm (can be arbitrarily selected).
Set Load 0.01 ~ 2.0 N, error not greater than ±1%.
Die Hole Diameter Ø5 mm.
Loading Rate Speed ≤ 10 mm/s when loading to the set value.
Steel Block Hardness HRC ≥ 60.
Test Consumable Aluminum foil.
Printing Method Each print can output 3 puncture force test data points, their average value, and the strength test result.
Shipping List & Power
Shipping List Main unit x1, Qualification certificate x1, Matching fixtures, Operation manual x1, Printer paper x1 roll, Matching weights.
Power Supply 220V / 50Hz.
Data & Physical
Data Saving Built-in needle printer / Can be saved to U drive for computer storage.
Net Weight 12 kg.
Overall Dimensions 400 * 240 * 240 (mm).
