500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
500mm Hydraulic Rebar Shear Line with 42kw Motor
Specifications
Place of Origin :
Sichuan, China
Brand Name :
GUTE
MOQ :
1
Price :
US$58,000
Voltage :
380V
Dimension :
30*5*3 m
Power :
42kw
Weight :
15000 kg
Cutting edge width :
500mm
Shearing mode :
Hydraulic shearing
Roller speed :
0-100m/min adjustable
Maximum shear length :
12m
Minimum shear length :
1.4m
Shear Accuracy :
±5mm
Shear frequency :
≤12n/min
Silo Series :
3
Rated power :
42kw
Total weight :
15t
Length Control Mode :
Servo
Description
Custom Cutting Edge Width 500mm Rebar Shear Line SGS150
Product Specifications
Attribute Value
Video Outgoing-Inspection Provided
Machinery Test Report Provided
Core Components Motor
Voltage 380V
Dimension (L×W×H) 30×5×3 m
Power (kW) 42
Attribute Value
Weight (kg) 15000
Warranty 1 Year
Cutting Edge Width 500mm
Shearing Mode Hydraulic shearing
Roller Speed 0-100m/min adjustable
Maximum Shear Length 12m
Product Description
500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor
CNC REBAR SHEAR LINE SGS150 is a high-performance hydraulic shearing machine designed for precision cutting of steel bars with various specifications.
  • PLC control system ensures high precision shearing, ideal for small batch processing
  • 24 fixed length plates with steel structure and servo motor for fast, accurate positioning
  • Large length blade with inclined design enables simultaneous cutting of multiple rebars
  • Centralized oil supply system for extended operational life
  • 3-level product storage mechanism for efficient collection
  • Thickened and widened gears with full encapsulation for stable cutting and enhanced safety
  • High-strength spiral elevator for precise positioning without deformation
  • Adjustable cutting length with continuous operation capability
  • Key-guided chains with rolling friction design for reduced wear and high transmission efficiency
Key Features
Straightening Structure
  • Forged alloy tool steel straightening wheel for superior wear and impact resistance
  • 30mm thick steel preset wheel plate for high strength and durability under impact loads
Multi-split Type Blade
  • Multi-split blade design doubles lifespan compared to standard one-piece blades
500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor
Servo Motor
  • 16KW high-power servo motor ensures smooth traction operation
Pneumatic Element
  • Premium Airtac (Taiwan) pneumatic components for extended service life
  • 40mm thick split blade design for multiple usage cycles
500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor
Pay-Off System
  • 2 pay-off units per machine with 2500KG maximum capacity each
  • Designed for easy disassembly and transportation
  • Optional brake customization available
Automatic Collector (Optional)
  • Automatically collects finished stirrups
  • Adjustable collection quantity for easy packaging
500mm Hydraulic Rebar Shear Line with 42kw Motor
Application
500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor
Production Line
500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor
Company Profile
500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor 500mm Hydraulic Rebar Shear Line with 42kw Motor
GUTE is a leading manufacturer of construction machinery with 28 years of experience and over 250 workers specializing in steel bar processing equipment.
  • Exported to over 70 countries with 70% export share in steel bar bender/cutter market
  • 200+ agents in China and 10 owned brand shops across provinces
  • OEM provider for renowned European brands
  • Global distribution including Russia, Italy, Brazil, Algeria, India, and Middle East
  • Expertise in reinforcement steel bar bending, shearing, welding, and straightening machines
  • Specialized in R&D and quality control for customized solutions
Transportation
500mm Hydraulic Rebar Shear Line with 42kw Motor
Frequently Asked Questions
Q: What's the producing time and delivery time?
A: Orders under 5 units are typically in stock with 5-day delivery to Shanghai port. Larger orders (5+ units) require 10-15 working days.
Q: What's the MOQ?
A: Minimum order quantity is 5 units. Sample orders (1 unit) are possible with additional port and delivery charges.
Q: What's the departure port?
A: Standard departure from Shanghai port, with options for Guangzhou, Qingdao, Tianjin, or other Chinese ports.
Q: What's the packing?
A: Secure packaging with iron pallets and poly wooden cases (no fumigation required).
Q: What's the payment term?
A: Multiple options including T/T, L/C, DP, West Union, and PayPal.
Our Service
  • 24-hour response to all product and price inquiries
  • Complete protection of your sales area, design concepts, and private information
  • Premium quality products at competitive prices
