500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
Specifications
Place of Origin :
Sichuan, China
Brand Name :
GUTE
MOQ :
1
Price :
$58,000
Voltage :
380V
Dimension :
30*5*3 m
Power :
42kw
Weight :
15000 kg
Cutting edge width :
500mm
Shearing mode :
Hydraulic shearing
Roller speed :
0-100m/min adjustable
Maximum shear length :
12m
Minimum shear length :
1.4m
Shear Accuracy :
±5mm
Shear frequency :
≤12n/min
Silo Series :
3
Rated power :
42kw
Total weight :
15t
Length Control Mode :
Servo
Description
Specification
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
CNC REBAR SHEAR LINE SGS150
◆ PLC control shearing precision, high precision of finished steel bar, suitable for shearing processing of
steel bar with many specifications and small batches.
◆ The machine has 24 fixed length plates, all of them are steel plate structure, with fixed length servo
motor, the fixed length is fast and accurate.
◆ Large length blade and inclined blade design are adopted to ensure that multiple reinforcing bars can
be cut at the same time.
◆ Equipped with centralized oil supply system to ensure long life operation.
◆ Level 3 product storage mechanism facilitates the collection of multiple products.
◆ Thickened and widened gears, stable and efficient cutting, fully encapsulated shield, effectively
enhance safety.
◆ The positioning screw adopts high strength spiral elevator, which is not easy to deform and has high
positioning accuracy.
◆ The cutting length can be set arbitrarily and work continuously. The speed block can be conveyed, and
the cutting accuracy of fixed length is high.
◆ Chains have keys as guide ways, and chains and guide ways are rolling friction. They have small wear
and tear, long service life and high transmission efficiency
Cutting edge width
500mm
Shearing mode
Hydraulic shearing
Roller speed
0-100m/min adjustable
Maximum shear length
12m
Minimum shear length
1.4m
Shear Accuracy
±5mm
Shear frequency
≤12n/min
Silo Series
3
Rated power
42kw
Total weight
15t
Long x wide x high
30m×5m×3m
Length Control Mode
Servo
Product Description
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine


Straightening Structure

* Straightening wheel for forging alloy tool steel manufacturing, wear resistance, impact resistance.
* Preset wheel plate: the overall use of 30mm thick steel plate, high strength, strong impact load, very durable.



Multi-split Type Blade

* The adoption of multi-split type blade which ensures a double lifetime compared with normal one piece blade.
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine


Servo Motor

* Equipped with 16KW high-power servo motor to ensure the smooth operation of traction.


Pneumatic Element

* pneumatic components adopt famous brand Airtac of Taiwan , ensure the service life.
* Split thickening blade design, thickness up to 40mm, easy to use for many times
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine


Pay-Off

* Each machine with 2 pcs pay-off.
* Each pay-off Maximum carrying capacity 2500KG.
* Be able to dis-assemble and easy to transport.
* You can customize the pay-off with brake.


Automatic collector
( Optional)

* Automatic collection of finished stirrups.
* The collection quantity can be set.Easy to pack finished products.
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
Application
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
Production Line
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
Company Profile
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
GUTE is the MANUFACTURER of construction machinery with 28 years history and more than 250 workers to produce steel bar processing machinery.
1. Now already exported more than 70 countries and 70% exporting share of steel bar bender/cutter
2. With more than 200 agents in Chinese market and 10 owened brand shops in different provinces in China.
3. We OEM for many very famous European brand for these kinds of machine.
Now, our machines already sold to Russia, Italy, Brazil, Algeria, India, Argentina, Saudi Arabia, Middle East and more than 70 countries and regions of the world.
We are reinforcement steel bar bending, shearing, welding, straightening machine provider. Expert with fast and professional customized services, in R&D and quality control of new products and special accessories for different market needs.We are having highly precise, durable semi-automatic and fully automatic steel bar machines.
Transportation
500mm Hydraulic Rebar Shear Line 42kw 380V Industrial Cutting Machine
FAQ
Q: What's the producing time and delivery time?
A: Order less than 5 pcs, we have stock, delivery to Shanghai port about 5 days. And order more than 5 pcs, about 10-15 working days.

Q: What's the MOQ?
A: 5 pcs. For sample order, 1 pc is OK, there's extra port and delivery charges.

Q: What's the departure port?
A: Usually Shanghai port, Guangzhou, Qingdao, Tianjin and other Chinese port is also OK.

Q: What's the packing?
A: Iron Pallet and Polly wooden cases (no fumigation needed)

Q: What's the payment term?
A: T/T, L/C, DP, West union, PayPal .
