fire fighting equipments, 5 inch canvas fire hose
fire fighting equipments, 5 inch canvas fire hose
Specifications
Longitude :
high intensity polyester short-fiber
Latitude :
high intensity polyester filament
Weave :
plain or twill
Length :
Max 30m
Work pressure :
8-16bar(8bar,10bar,13bar,16bar)
Inner diameter :
1-10inch(19mm,25mm,40mm,50mm,65mm,etcs)
Lining :
Rubber/ PVC/ PU
Oil :
best (DOP)
Certificate :
CCCF, ISO9001
Use :
fire fighting agricultural use industrial use transport liquid
Description

fire fighting equipments
-Jacket woven by high tenacity polyester yarn
-Low water-flow resistance
-Working Pressure 8-20Bar

fire fighting equipments, canvas fire hose

1)PVC Lining

2)The jacket of canvas fire hose is woven by high intensity of polyester filament or polyester short-fiber( twill/plain weave)

3)There are special adhesive ( solid or liquid)between the jacket and the hose. The hose is soft and highly polished,reduce the flow resistance.

4) Thinner, softer, lighter and more convenient to use.
5) High pressure resistance, low temperature resistance, anti-corrosion. aging resistance.wear-resisting.
6) We can provide different color lining: blue, black, transparent, etc or according to your requirement

7) We can provide length: 10m - 40m or according to your requirement

Technical Parameters:

Diameter

(Inch/mm)

Working Pressure

(MPa/BAR/PSI)

Testing Pressure

(MPa/BAR/PSI)

Bursting Pressure

(MPa/BAR/PSI)

Length

(M/FEET)

1 25

1.0/10/150

1.3/13/195

1.6/16/240

2.0/20/300

1.5/15/220

2.0/20/300

2.4/24/360

3.0/30/450

3.0/30/450

3.9/39/580

4.8/48/720

6.0/60/900

10

15/50

20

25

30/100

1-1/2 40

2 50

2-1/2 65

3 80

3-1/2 90

4 100

4-1/2 115

5 125

5-1/2 140

6 150

fire fighting equipments, canvas fire hose producing details
