pendent fire sprinkler

Finishes: chrome
Buld:5mm/3mm
Orifice Size:1/2'', 3/4"
Nominal operating temperature:68 Celsius degree

Brief introduction and application

Sprinkler is an important part of wet-type auto spraying system. It is usually installed inside the building and structures with light fire danger, medium fire danger and heavy fire danger, such as workshop, warehouse, hotel, shop, recreational place, hospital, cinema, office building and garage.
The sprinkler is composed of sprinkler frame, sealant and glass bulb. It is to be installed in the protective district via ductwork, acting as a fire detector and auto sprayer. In case of fire inside the protective district, the atmosphere temperature rises up and the liquid inside the glass bulb expands after being heated and explodes after reaching the operating temperature of the glass ball. The sealant drops and the sprinkler sprays to the protective district for fire extinguishments subject to the preset shape of spraying.

The sprinklers of the pendant installation,ZST-15/20 Fiire Sprinkler Feature:

Bulb:5 mm/3 mm

Finishes:Chrome

Orifice Size:1/2'', 3/4"

Nominal operating temperature:68 Celsius degree

Nominal pressure:12Bar(1.2MPa)

Airproof test pressure:30bars(3.0Mpa)

Outlet:11 ± 0,2mm

Factor K:80,0

Height: 54 ± 0,8mm

Width:27,5 ± 0,5 mm

Package:200pcs packing in a carton box
