ASTM F899 Material EN 1.4568 DIN X7CrNiAl17-7 17-7PH Stainless Steel Sheet And Strip
ASTM F899 Material EN 1.4568 DIN X7CrNiAl17-7 17-7PH Stainless Steel Sheet And Strip
ASTM F899 Material EN 1.4568 DIN X7CrNiAl17-7 17-7PH Stainless Steel Sheet And Strip
ASTM F899 Material EN 1.4568 DIN X7CrNiAl17-7 17-7PH Stainless Steel Sheet And Strip
Specifications
Model Number :
EN 1.4568 DIN X7CrNiAl17-7 17-7PH
Size range :
0.1~6.0x300mm
Price :
Negotiable
MOQ :
500 kgs
Delivery Time :
15 days after receipt 30% of value
Brand Name :
Daway
Product :
17-7PH stainless steel strip, coil and sheet
Place of Origin :
China
Corrosion resistance performance :
comparable to 304 stainless
Payment Terms :
T/T
Certification :
EN 10204 3.1
Max. service temperature :
316℃
Supply Ability :
200 tons per month
Packaging Details :
Seaworthy
Description

ASTM F899 Material EN 1.4568 DIN X7CrNiAl17-7 17-7PH Stainless Steel Sheet And Strip

Material 1.4568, also referred to as X7CrNiAl17-7, 17-7PH

a precipitation-hardenable austenitic stainless steel combining high strength, toughness and excellent corrosion resistance.

Its heat treatment capability allows tailoring the mechanical properties to specific requirements,

making it a versatile choice for demanding applications.

1.4568 is widely used in aerospace, medical technology, mechanical engineering and automotive industries,

especially for highly stressed springs, clips, clamps, diaphragms, valve components and precision parts.

Typical chemical composition %

C Si Mn P S Cr Ni Al
0.09 1.00 1.00 0.040 0.030 16.00-18.00 6.50-7.50 0.75-1.50

Specification

  • ASTM F899 AISI 631, UNS S17700, 17-7PH
  • ASTM A693
  • AMS 5529, sheet, strip, cold rolled
  • AMS 5528 sheet, strip and plate
  • DIN EN 10151 EN 1.4568 DIN X7CrNiAl17-7

Mechanical properties

Condition Tensile strength Hardness Age treatment
Solution annealed, condition A 150 ksi max. 1000 Mpa max. HRB 92 max. TH1050, RH950

Spring temper,

condition C

 200 ksi min, 1380 Mpa min. HV 400 min. CH900

Applications

  • Springs
  • rings
  • washers
  • tubing
  • clips, clamps

Form of supply

17-7PH stainless steel strip, coil, cut lengths sheet, plate

For Details, please Contact

Wuxi Guanglu Special Steel Co., Ltd. – your productivity partner for precision strip steel.

We are looking forward to your enquiries.
Please call +86 510-8181-2873
or send an email to export@guanglusteel.com
