Cold Rolled Stainless Steel Coil JIS SUS631-CSP 3/4H
Cold Rolled Stainless Steel Coil JIS SUS631-CSP 3/4H
Cold Rolled Stainless Steel Coil JIS SUS631-CSP 3/4H
Cold Rolled Stainless Steel Coil JIS SUS631-CSP 3/4H
Specifications
Precipitation hardening steel :
SUS631
Product :
Cold rolled stainless steel strip coil SUS631-CSP
Form of supply :
SUS631 stainless steel strip, coil, and sheet
Specification :
JIS G4313 Cold rolled stainless steel strip for springs
Size :
0.1~3.0x3~420mm
Brand Name :
Daway
Model Number :
SUS631-CSP
Certification :
EN 10204 3.1
Place of Origin :
China
MOQ :
500 kgs
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 tons per month
Delivery Time :
15 days after receipt 30% of value
Packaging Details :
seaworthy
Delivery condition :
Solution treated, 1/2H, 3/4H, H
Description

Cold Rolled Stainless Steel Coil JIS SUS631-CSP

Precipitation hardening steel JIS SUS631, 17-7PH, UNS S17700, EN 1.4568, DIN X7CrNiAl17-7

is a semi-austenitic stainless steel which is austenitic in the annealed condition, but martensitic in

the hardened condition. Type 631 provides high strength and hardness, excellent fatigue properties,

good corrosion resistance and minimum distortion upon heat treatment.

It is easily formed in the annealed condition, then hardened to high strength levels by simple heat

treatments to Conditions RH 950 and TH 1050.

The exceptionally high strength of Condition CH 900 offers many advantages where limited ductility

and workability are permissible. In its heat treated condition, this alloy provides exceptional mechanical

properties at temperatures up to 900 °F (482 °C).

Chemistry typical

C Si Mn P S Cr Ni Al
0.09 max 1.00 max 1.00 max 0.040 max 0.030 max 16.00~18.00 6.50~7.75 0.75~1.50

Applications

Springs, Washers, Clips, Surgical parts, Blades, Bellows, Honeycomb

Forms

Stainless steel shim SUS631 17-7PH coil / strip / sheet

Standard JIS G4313 Cold rolled stainless steel strip for springs

Grade Finish As cold rolled, or either as solution treated or as annealed As precipitataion hardened
Hardness HV Bendability Symbol of heat treatment Hardness
SUS301-CSP 1/2H ≧310 ≦Twice of the thickness - -
3/4H ≧370 ≦2.5 times of the thickness - -
H ≧430 - - -
EH ≧490 - - -
SEH(1) ≧530 - - -
SUS304-CSP 1/2H ≧250 ≦Twice of the thickness - -
3/4H ≧310 ≦2.5 times of the thickness - -
H ≧370 - - -
SUS631-CSP 0 ≧200 ≦0.5 times of the thickness TH1050
RH950		 ≧345
≧392
1/2H ≧350 ≦1.5 times of the thickness CH ≧380
3/4H ≧400 - CH ≧450
H ≧450 - CH ≧530
