ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil
ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil
ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil
ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil
ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil
ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil
Specifications
Brand Name :
Daway
Model Number :
17-4PH
Certification :
SGS
Place of Origin :
China
MOQ :
500 kgs
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 tons per month
Delivery Time :
15 days after receipt 30% of value
Packaging Details :
seaworthy
Precipitation hardening steel :
17-4PH
Product :
17-4PH Cold Rolled Stainless Steel Sheets , Strips, Coils
Size range :
0.1~3.0X420mm
Delivery condition :
Solution Annealed
Description

ASTM A693 UNS S17400 Cold Rolled Stainless Steel Strip 630 Stainless Steel Coil

17-4PH precipitation hardening stainless steel (UNS S17400 - EN 1.4542 - DIN X5CrNiCuNb16-4 - SUS630)

17-4PH is a chromium-nickel-copper precipitation hardening stainless steel used for applications requiring

high strength and a moderate level of corrosion resistance.

High strength is maintained to approximately 600°F (316°C).


The S17400 alloy is martensitic in structure in the annealed condition and is further strengthened

by a low temperature treatment which precipitates a copper containing phase in the alloy.

In comparison to many alloys in the precipitation hardening family, the S17400 alloy requires a simple heat treatment;

a one step process conducted at a temperature in the range 900°F (482°C) to 1150°F (621°C)

depending on the combination of strength and toughness desired.

A wide range of properties can be produced by this one step heat treatment.

Heat treatment in the 900°F (482°C) range produces highest strength.

We supply 17-4PH stainless in sheet, strip, and plate product forms.

17-4PH is produced in compliance with aerospace specifications such as AMS 5604

and standard industrial specifications such as ASTM A693 and ASME SA-693.

Chemical composition % weight typical

Grade C Si Mn P S Cr Ni Cu Nb
630 0.04 0.5 0.4 0.020 0.005 15.5 4.5 3.5 0.3

Product forms

17-4PH precipitation hardening stainless steel is furnished as plate, sheet, strip and long products.

In all forms, the material is furnished in the annealed condition
