Specifications
Brand Name :
Daway
Model Number :
AISI 420MoV EN 1.4116 DIN X50CrMoV15
Place of Origin :
China
Certification :
SGS
MOQ :
1 ton
Payment Terms :
T/T
Supply Ability :
500 tons per month
Delivery Time :
15 days after receipt 30% of value
Packaging Details :
seaworthy
Price :
negotiable
Material :
AISI 420MoV EN 1.4116 DIN X50CrMoV15
Size :
0.1~10.0*1250mm
Delivery state :
annealed
Surface :
2B, No.1
Description
AISI 420MoV EN 1.4116 DIN X50CrMoV15 Stainless Steel Sheets And Plates

This is a medium carbon martensitic stainless steel with moderate corrosion resistance good strength

and the ability to obtain and keep excellent hardness (Rc 56) and wear resistance.

Material C Si Mn Cr Mo V

W.-nr. 1.4116

DIN X50CrMoV15 )

 0.45 ~ 0.55 1.00 max 1.00 max 14.00 ~ 15.00 0.50 ~ 0.80 0.10 ~ 0.20

X50CrMoV15 - a special alloy for knives, blades

X Stainless steel

50 0.5% carbon - the carbon content is significant for the sharpness

Cr Chromium for stain-resistant properities

Mo Molybdenum enhances the stain-resistant properities

V Vanadium for hardness and edge retention

15 Contents of chromium in % ( 15% )

Special characteristics

  • razor sharp
  • long-lasting cutting edge
  • high stain resistance
  • easily restorable edge

Mechanical properities ( to EN 10088-2 )

Rm

( Tensile strength ) N/mm2

A5

( elongation ) %

A80

( elongation ) %

Harness

HB
max. 850 ≥ 12 ≥ 12 ≤ 280
  • Hardened and tempered approx. 55 - 57 HRC.

Heat treatment

Hardening

Hardening temperature Cooling Holding time
980 - 1050°c Oil / Air 3.5 min/mm

Tempering

Tempering temperature Holding time Hardness
150 - 200°c 1 - 2 hours 55 - 57 HRC

For Details, please Contact

WUXI GUANGLU Special Steel Co., Ltd.

Stainless martensitic • precipitation hardening steel • stainless ferritic — Our answer to your needs

Tel: +86 510 81812873

Email: export@guanglusteel.com
