| NO. | Item | General Parameter | Remark | ||||
|---|---|---|---|---|---|---|---|
| 1 | Model | LK12.8-40 | |||||
| 2 | Standard capacity(0.2C5A) | 40Ah | |||||
| 3 | Minimum Capacity(0.2C5A) | 39Ah | |||||
| 4 | Rated voltage | 12.8V | |||||
| 5 | Max Charge voltage | 14.6V | |||||
| 6 | Cut-off voltage | 8.8V | |||||
| 7 | Standard charge and discharge current | 10A | |||||
| Maximum Continuous Charge Current | 40A | ||||||
| 8 | Max Continuous discharge current | 40A | |||||
| 9 | Weight(Approx including case) | ≈ 5.3 Kg | |||||
| 10 | Impedance(Max, at 1000Hz.) | ≤8mΩ | Includes test fixture internal resistance | ||||
| 11 | SOC Battery Shipping SOC | 30%±5% SOC | Air freight | ||||
| 65%±5% SOC | Sea transport | ||||||
