LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
LiFePO4 Battery Pack 48V 100Ah 4.8KWH Rack Mounted Energy Storage Battery for UPS Power Station
Specifications
Brand Name :
G Tech
Model Number :
LR-4.8K
Certification :
UN38.3 MSDS
Place of Origin :
China
MOQ :
50
Price :
USD500-USD600
Payment Terms :
T/T
Supply Ability :
100000 pieces per month
Delivery Time :
5-7 work days
Packaging Details :
carton, wooden
Material :
LiFePO4
Voltage :
48V
Capacity :
100Ah
Energy :
4.8KWH
Description
Product Advantages
  1. LiFePO₄, Gel, and Deep Cycle battery solutions
  2. Compatible with major inverter brands
  3. OEM and customized energy storage solutions
For solar energy storage
No.ItemParameterRemark
1ModelLR-4.8KPrismatic battery-100Ah
2Standard capacity ( 0.2C5 A )100Ah
3Minimum Capacity ( 0.2C5 A )98Ah
4Energy4.8 KWh
5Rated voltage48V
6Maximum charging voltage54.75V
7Discharge cut-off voltage37.5V
8Standard charge and discharge current20A
Maximum charging current100ASee charging table
9Maximum continuous discharge current100ASee discharge table
10Installationrack-mounted
11CommunicationCAN/RS485
12Battery protectionOver charge/over discharge/over temperature/over current/ short
13Level of protectionIP54
14Weight(Approx including case)≈ 30.6 kg
15Internal resistance (Max, at 1000Hz. )≤ 15 mΩIncludes test fixture internal resistance
16Support inverter interaction protocolRS4851. Pylontech; 2. Growatt; 3. Voltronics; 4. Lux Power; 5. Deye; 6. IVT; 7. SRNE
CAN1. Pylontech; 2. Victron; 3. Goodwe; 4. Growatt; 5. Lux Power; 6. Deye; 7. Sofar Solar; 8. Solis; 9. SMA; 10. Others .
17Cycle lifeSOC≥80% initial capacity @ room temperature ≥ 2500 cycles 0.5C charge 0.5C discharge DOD80%
18Delivery voltage≥ 48 V
19Charging method (CC/CV)standardCC20A54.75V cutoffwith constant current and voltage of 20A to 54.75 V, then switch to constant voltage charging at 54.75V until the charging current is less than or equal to 0.05C.
CV54.75V5A cutoff
20Operating temperatureCharge0 ℃～ 65 ℃
Discharge-20 ℃～ 65 ℃
Storage-20 ℃～ 45 ℃
