Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Lab Research Pouch Cell Assembly Equipment Electrode Punching
Specifications
Applicable Industries :
pouch cell Battery
electrode size :
280x180mm
Description
Product Description
The semi-automatic electrode die-cutting machine is a highly efficient and mass produced flexible packaging positive and negative electrode sheet forming equipment. It is also a convenient and fast multi-functional laboratory flexible packaging lithium battery, positive and negative electrode sheet forming experimental and production equipment.
Features:
1.Roll or sheet electrode feeding, knife template for die cutting;
2.It is convenient and quick to replace the knife mold (the life of the knife mold is about 30000 times for consumables);
3.Pneumatic pressurized cylinder drive, adjustable punching force and flatness;
4.Die-cutting products have small burrs, no peeling, no indentation, and other poor appearance;
5.Easy to operate, safe and reliable, beautiful appearance, small size
Specification
Voltage
220V/50Hz
Power
100W
Compressed air
0.5Mpa ~0.8 Mpa
Maximum punching size
280x180mm(The maximum punching size can also be unlimited according to customer requirements)
Booster cylinder
3T
Cutting accuracy
±0.1 mm
Size
L550xW455xH900mm
Weight
180kg
