Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
Specifications
Brand Name :
Litong Global
Model Number :
LT-61206
Certification :
ISO9001-2008
Place of Origin :
ANHUI,CHINA
MOQ :
Negotiable
Price :
Negotiable
Supply Ability :
1000tons/day
Packaging Details :
Standard export seaworthy packing in coil with 2.5-3.2tons/coil on 2 pallets
Material :
steel wire
Cross Sectional Shape :
Round
Application :
Construction wire mesh
Metal Wire Drawing :
Hot Drawing
Structure :
1*7
Alloy or Not :
Not-alloy
Relaxation at 1000h Not More Than :
2.5%
Coil Size :
ID 0.70-0.72m, Od 1.0-1.5m, Width 0.76m
Elongation at Max Load Not Less Than :
3.5%
Specification :
Astma416, Bs5896, En10138-3, as/Nzs4672, GB/T5224
Description

Product Description

Low Relaxation Prestressing Concrete Strand

High tensile strand for pre-stresses in concrete structure by virtue of improved proportional limit, higher ductility combined with higher strengths. They may be supplied in drawn or drawn straightened or stress relieved conditions. They can also be supplied in plain or indented finish. These are manufactured to different international standards and to the specific requirement of each customer.


---------------Specification-------------
1. Nominal Dia.:
1*7-9.5mm 9.53mm 12.7mm 15.2mm15.7mm 17.8mm 21.6mm

2. Tensile Strength: 1470Mpa ~ 1960Mpa
Yield Strength: 1320Mpa ~ 1760 Mpa
Elongation: Not less than 3.5%
Initial Load: Not more than 70%
Relaxation(1000h): 2.5%
Type: Cold drawn wire
Raw Material: SWRH77B/82B Wire Rod

3. Other Diameters are available as per customers' request.
4. Standard: ASTMA416, BS5896, EN10138-3, AS/NZS4672, GB/T5224, KS7002, ISO6934-4, JISG3536.
5. Application: Construction material, widely used
6. Packing and weight: Coil at customer's requirement. (water-proof packing with wood pallets)
7. Minimum order: 20-25tons
8. Payment term: T/T or L/C

-------------Features--------------
1. Low relaxation
2. High tensile strength
3. Perfect Machinability

7-Wire Uncoated Steel Strand for Prestressed Concrete as per ASTM A 416

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

 Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation
MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.53

+0.66,-0.15

 54.84 432 102.3 92.1

≥3.5

≤2.5
11.11 74.19 582 137.9 124.1
12.70 98.7 775 183.7 165.3
15.24 140.0 1102 260.7 234.6
17.80 190.0 1492 353.0 318.0
2000 12.70 +0.66,-0.15 98.7 775 197.4 177.7 ≥3.5 ≤2.5
15.24 140.0 1102 280.0 252.0

7-Wire Uncoated Steel Strand for Prestressed Concrete as per GB/T5224

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

 Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation
MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.50 +0.30,-0.15 54.8 432 102 86.6

≥3.5

≤2.5
11.10 74.2 580 138 117
12.70

+0.40,-0.20

 98.7 775 184 156
15.20 140 1101 259 220
15.70 150 1178 279 251
17.80 191 1500 353 318
1960 12.70 +0.40,-0.20 98.7 775 193 174 ≥3.5 ≤2.5
15.20 140 1101 274 247

Welcome to enquiry our PC Strand

Low Relaxation Non alloy PC Steel strand As per ASTM A416-06 Grade 270K
