ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
ASTM A475 Galvanized Steel Core Wire Low Stress For ACSR Conductor
Specifications
Place of Origin :
Anhui ,China
Brand Name :
Litong Global
Certification :
ISO9001
Model Number :
LT-150922
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
In Coil or On Drum
Delivery Time :
10 days after confirmed order or as per order quantity
Payment Terms :
TT/LC
Supply Ability :
400tons/day
Steel Grade :
High Carbon Wire Rod
Wire Gauge :
1.0-4.8mm
Type :
Galvanized
Application :
Rope
Alloy Or Not :
Non-alloy
Special Use :
Free Cutting Steel
Standard :
AISI|ASTM|BS|DIN|GB|JIS
Description

GALVANIZED STEEL WIRE STRAND SPECIFICATION AS BELOW:

1. Galvanzied steel wire strand for

ground wires, steel core for ACSR, Stay wires ,Guy wires, Messengers

2. Galvanized steel wire strand Specification: 1X7, 3.00---12.60MM

1X19, 5.00---19.00MM

3. Galvanized steel wire strand Standard: ASTM-A475(03), BS 183

4. Galvanized steel wire strand packing: 5000ft/1524mts/reel

ASTM A 475-2003

Norminal Diameter

No.of wires

Diameter of wire

Tolerance of wiere

Weight

Zinc coating

Broken Loading

Inch

mm

pcs

mm

± mm

Kgs/100M

G/M2

Lbf

Kn

1/8"

3.18

7

1.04

0.05

48

122

1830

8.14

5/32"

3.97

7

1.32

0.05

76

122

2940

13.078

3/16"

4.76

7

1.57

0.08

109

153

3990

17.748

7/32"

5.56

7

1.83

0.08

146

153

5400

24.02

1/4"

6.35

7

2.03

0.08

180

183

6650

29.581

9/32"

7.14

7

2.36

0.10

244

214

8950

39.812

5/16"

7.94

7

2.64

0.10

305

244

11200

49.82

3/8"

9.52

7

3.05

0.10

407

259

15400

68.503

7/16"

11.11

7

3.68

0.13

595

275

20800

92.523

1/2"

12.7

7

4.19

0.13

770

275

26900

119.657

9/16"

14.29

7

4.78

0.13

1000

305

35000

155.688

5/8"

15.88

7

5.26

0.13

1211

305

42400

188.605

Test Equipments
