Specifications
Brand Name :
Litong Global
Model Number :
LT-180623
Certification :
ISO9001-2008,SGS etc.
Place of Origin :
Anhui,China
MOQ :
10tons
Price :
discuss
Supply Ability :
800tons/day
Packaging Details :
standard export packing in coil on 2 pallets
Material: :
82B speed wire rod
Relaxation at 1000h Not More Than: :
2.5%
Elongation at Max Load Not Less Than: :
3.5%
Alloy or Not: :
Non-Alloy
Structure: :
1x7
Coil Size: :
ID 0.70-0.72m, Od 1.0-1.5m, Width 0.76m
Tensil Strength: :
more than 1860MPA
Packing: :
2.5-32tons/coil
Description

High Tensile PC Steel Wire For Post Tensioned And Pre Tensioned Concrete Structure

0.5"(12.7mm)PC Steel Wire Strand Grade 1860 with high strength low relaxation

Product Description

1*7 Wires Low Relaxation PC Strand
Description:
High tensile low relaxation steel strand for prestressed concrete
Specification:
Raw Material: High carbon steel wire rod SWRH 82B

Sizes:12.5, 12.7, 12.9, 15.2, 15.7, 17.8mm

Standards: ASTM A416-2006, ASTM A910-2005, ABNT NBR 7483:2008, AS 1311(Australia), AS/NZS 4672.1, BS5896-1980, EN10138-3, GB/T5224-2003, IS6006-1983, JISG3536, KSD7002, UNE36094-97 (Spain), NEN3868

Tensile Strength over 1860MPa, Yield Strength over 1670MPa
Initial load to 70% breaking load, the relaxation at 1000 hours less than 2.0%
Lo over 610mm, the elongation over 4.0%
Package: baling strip, inner PVC film, outer damp-proof paper-plastic compound packing cloth, wooden pallet pedestal.
Package Weight: 2.5-3.2 tons per coil

High Tensile PC Steel Wire For Post Tensioned And Pre Tensioned Concrete Structure

Standard Grade Nonimal Dia. Section Area Mass Breaking Loading Load at 1% Ext. Elongation Relaxation at 1000h
(in) (mm) (mm2) (g/m) Min (Mpa) (KN) Lo 610mm min (Initial Load to 70% of Breaking Load)
ASTM A416 270K (1860) 3/8 9.53 54.84 432 102.3 92.1 3.5% min Low Relaxation Normal Relaxation
7/16 11.11 74.19 582 137.9 124.1 2.5% max 3.5% max
1/2 12.7 98.71 775 183.7 165.3
3/5 15.24 140.00 1102 260.7 234.6
Standard Type Dia. Tolerance Section Area Mass Tensile Strength Breaking Loading Min. Load at 1% Extenstion Elongation 1000h Relaxation
(mm) (mm) (mm2) (g/m) (Mpa) Min. (KN) Min (KN) Min (%) Max (%)
BS5896 -1980 Standard 7 Wire 9.3 +0.3, -0.15 52 408 1770 92 81 3.5 2.5%
11.0 71 557 1770 125 110
12.5 +0.4, -0.2 93 730 1770 164 144
15.2 139 1090 1670 232 204
Super 7 Wire 9.6 +0.3, -0.15 55 432 1860 102 90
11.3 75 590 1860 139 122
12.9 +0.4, -0.2 100 785 1860 186 163
15.7 150 1180 1770 265 233

Usages:
Pre-stressing steels apply to post-tensioned and pre-tensioned concrete structure in the follow civil engineering, building construction and infrastructure projects: bridges; railway sleeper, subway track board; airport; industrial buildings, commercial buildings, residential housing foundations; PC poles, piles, beams, girders, slabs, double-T board, hollow floor board, floor, parking decks, PHC, PPCP; electric power, nuclear power station; ports, dams, water project, sewage treatment, swimming pool; rock-coil anchoring, side slope stabilization, coil mine; storage tank for national gas, oil, grain; stadiums, TV tower etc.
