Specifications
Brand Name :
ClingSeal
Model Number :
CS2070T
Certification :
ISO9001 UKAS, 100% no asbestos
Place of Origin :
CHINA
MOQ :
500KGS
Price :
1.07 USD PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100Tons per month
Delivery Time :
10-20 days
Packaging Details :
wooden case
Customer Service :
Available for Q&A
Material :
Non-asbestos fiber, rubber
Product Formation :
Two sides perforated metal with non asbetos insert
Application :
Sealing and Gasketing
Shape :
Sheet
Features :
Good adaptability, durability, sealing, no delamination, high yield, economical, good oil-resistance
Size Options :
Thickness 1.0-6.0mm, Size variations: 500*500mm, 500*1000mm, 500*1500mm, 1000*1000mm, 1000*1500mm, Customizable
Tensile Strength :
≥8 MPa
Length :
1000mm
Density :
1.6-2.0 g/cm3
Temperature Resistance :
Up to 350°C
Compression Strength :
20MPa
Pressure Resistance :
Up to 20MPa
Color :
Black
Thickness :
0.5mm
Elongation At Break :
200%
Width :
1000mm
Compression Ratio :
≤12%
Elongation :
≥200%
Standard Size :
1000mm x 1000mm, 1500mm x 1500mm
Acid Resistance :
Excellent
Compressibility :
≤12%
Hardness :
70-80 Shore A
Alkali Resistance :
Good
Recovery :
≥40%
Description

Perforated Steel Core Cylinder Head Gasket Sheet – Non-Asbestos, Oil Resistant, and Heat Stable Solution

Overview

Our Perforated Steel Core Cylinder Head Gasket Sheet is a high-performance sealing solution engineered for tough working environments. Crafted with non-asbestos materials and reinforced by a precision-perforated steel core, it delivers reliable sealing in extreme temperatures, making it ideal for industries across Latin America, the Middle East, and Southeast Asia. Compliant with global safety and environmental standards, this gasket sheet balances durability, adaptability, and cost-effectiveness—designed to meet your region’s unique operational needs.

Core Benefits

Advanced Material Engineering

  • Dual-layer structure: Non-asbestos fiber matrix reinforced with a laser-perforated steel core (0.2–0.25mm thick, available in carbon steel, SS201, 304, or 316) for enhanced strength.
  • Extreme durability: Withstands temperatures from -50°C to 350°C (suitable for high-heat environments like Middle Eastern refineries) and resists oil, ozone, and natural gas corrosion.
  • No asbestos, 100% safe: Certified asbestos-free, meeting ISO 9001 UKAS, SAE J1066, and EU RoHS/REACH standards—ensuring compliance with regional safety regulations.

Structural Reliability

  • Stable under thermal cycles: The perforated steel core reduces warping and delamination, even with repeated heating and cooling.
  • Consistent sealing: 18% compression resilience maintains a tight seal in dynamic applications (e.g., automotive engines, industrial machinery).
  • High yield rate: Minimizes waste with precise manufacturing, lowering long-term costs for bulk users.
​

Target Applications by Region

  • Latin America: Perfect for automotive and marine engine head gaskets, replacing traditional asbestos-based materials in vehicles and boats.
  • Middle East: Ideal for high-temperature flange seals in petrochemical refineries and reactor systems, where heat and oil resistance are critical.
  • Southeast Asia: Suitable for industrial machinery, precision equipment thermal dissipation modules, and general-purpose sealing in factories and workshops.

Customization Options

Tailored to your specific needs:
  • Thickness: 0.5mm–6.0mm (single sheet: 0.5–3.0mm; dual-layer: 1.0–6.0mm) with ±0.05mm tolerance.
  • Sizes: Standard 500x500mm, 500x1000mm, 1000x1000mm, or custom dimensions on request.
  • Value-added services: Prototyping, material compatibility testing, and DFMEA analysis to ensure fit for your equipment.

Order & Logistics Details

  • Minimum order: 500 KGS.
  • Price: 1.07 USD per KG (competitive bulk rates available).
  • Payment: Convenient via T/T, Western Union, or MoneyGram.
  • Supply capacity: 100 tons/month, ensuring steady stock for large-scale projects.
  • Delivery: 10–20 days, with secure packaging in wooden cases to prevent damage during transit.
  • Shipping: Partnered with UPS and FedEx for reliable delivery; tracking provided for full transparency.

Our Support

We stand behind your purchase with:
  • Expert advice on product selection and application matching.
  • Installation guidelines and best practices for optimal performance.
  • Troubleshooting support for any on-site issues.
  • Quality warranty and regular updates on product improvements.
Built to thrive in your region’s toughest conditions—this gasket sheet is more than a seal: it’s a long-term solution for reliability and safety.


Physical Property:

Item
Compressibility % 8-17
Recovery % ≥35
150ºC,At ASTM 3#Oil for 5hours Weight Increas % ≤30
Thickness Increas % ≤20
At 21ºC~30ºC,ASTM B Fuel for 5hours Weight Increas % ≤30
Thickness Increas % ≤20
  • Product Technical Details
    As a general rule, exhaust gasket sheet is:
    • Good for use with steam
    • Good for high temperature
    • Good with high pressure

Support and Services:

Our Product Technical Support and Services for the Non asbestos gasket sheet include:

- Expert consultation on product selection and applications

- Installation guidance and best practices

- Troubleshooting assistance for any issues related to the gasket sheet

- Regular product training and updates for users and technicians

- Quality assurance and warranty coverage for our products

Packing and Shipping:

Product Packaging:

The non-asbestos gasket sheet is carefully wrapped in protective plastic film to prevent any damage during transportation. It is then placed in a sturdy cardboard box with sufficient cushioning material to ensure safe delivery.

Shipping Information:

We ship our non-asbestos gasket sheet product using reliable courier services such as UPS or FedEx. The product will be securely packaged to prevent any damage in transit. Customers will receive a tracking number to monitor the shipment status and estimated delivery date.

FAQ:

Q: What is the brand name of the non asbestos gasket sheet product?

A: The brand name is ClingSeal.

Q: What is the model number of the non asbestos gasket sheet?

A: The model number is CS1070T.

Q: Where is the non asbestos gasket sheet produced?

A: The product originates from China.

Q: What certifications does the non asbestos gasket sheet have?

A: The product is certified with ISO and SGS.

Q: What are the available payment terms for purchasing the non asbestos gasket sheet?

A: Payment can be made via T/T, Western Union, or MoneyGram.
