500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace
500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace
500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace
500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace
Specifications
Brand Name :
PAM
Model Number :
5HPX-30
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1set
Payment Terms :
L/C, T/T
Supply Ability :
100 sets per month
Delivery Time :
5-8 working days if no customization parts
Packaging Details :
standard export wooden cases
Type :
batch type
Usage :
grain drying
Condition :
new
Body dimension :
2900*2260*12700mm
Air consumption :
10000-14000 m3/h
Power :
19.7kw
Description

500 tons paddy dryer plant manufactuer in China 500 tons paddy dryer project supplier

Rice Husk Furnace Drying Complex
For 500 Tons project,need two Husk furnace and 17 sets 30 tons dryer,one furnace drive 10 sets dryer,and another drive 7 sets dryer,so could able to reach 500 tons capacity per batch

One 200 Furnace With 10 Sets 30 Tons Dryer

500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace

500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceHusk Feeder 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceHusk Tank
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceRice Husk Furnace SB-200 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceMain Control Box
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceAuto Ash Discharger 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceAuxiliary Air Blower
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceCyclone 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceHot Air Duct
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceDumping Pit 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceBucket Elevator
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnacePrecleaner 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceBucket Elevator
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceLoading Chain Conveyor 500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace32 ton husk type grain dryer
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceMicro Air Adjuster 500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceHot Air Damper
500 Tons Paddy Parboiling And Drying Machine Two Husk FurnaceUnloading Chain Conveyor

Technical Parameters

30 Tons Dryer

Model 5HPX-30
Loading capacity 30 Tons
Dimension 2900*2260*12700mm
Drying Type Low Temperature circulating Type
Power For Fan 5.5 KW*2
Drying Rate 0.6~1.4%Per Hour
Heat Consumption <30,000 KCalorie
Weight 6,000KG
Standard Device Moisture Meter,Conveyor,Fan









2 Million Kcal Husk Furnace

Model 5LXF-100 5LXF-150 5LXF-200
Burning Method Cyclonic Furnace
Fuel Husk
Heating Mode Indirect
Heat Exchange Square 88㎡ 138㎡ 188㎡
Heat Efficiency ≥80 % ≥80 % ≥80 %
Husk Consumption 100~265 kg/h 220~550 kg/h 260~650 kg/h
Ash Discharge kg/h 20-50 kg/h 40-95 kg/h 45-110 kg/h
Dimension (mm) 3200*4500*2850 5900*6430*8520 6790*6560*9250
Power (kw) 9.05 17.55 21.05
Weight (kg) 12000 25000 30000
Safety Devices Abnormal combustion sensor, Flame sensor, Automatic abnormal safe guard, Thermal relay, Rotation sensor, Control fuse
Supply Dryer Quantities 5HPX-15 5 sets 5HPX-15 7 sets 5HPX-15 9 sets
5HPX-20 4 sets 5HPX-20 7 sets 5HPX-20 9 sets
5HPX-30 2 sets 5HPX-30 5 sets 5HPX-30 6 sets

Application

500 Tons Paddy Parboiling And Drying Machine Two Husk Furnace

What We Can Offer

1) Whole turnkey project solution
included pre-cleaning machine,elevator,conveyor these essential equipment could also given from ourside
2) Plant design service
supply you all the possibly area required,the instllation diagram and draws for consideration
3) Instllation and commisioning service
professional engineer woud guide you for the assembling and commisioning of the machine
4) Full time online service
24 hours online technique service,ensure to solve the problem immediately
5) Enormous spare parts to support
easy broken spares and wearing parts would be send timely,no worry for drying season
