Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Small Paddy Dryer One-click Intelligent Automatic Control
Specifications
Brand Name :
WANGU
Model Number :
WGHH15-30
Place of Origin :
ZHENGZHOU,HENAN
Moisture Content :
≤14%
Product Name :
Small Grain Dryer
Weight :
5-6t
Capacity :
10-30t/h
Dimension :
3*3*13m
Control System :
One-click Intelligent Automatic Control
Power :
18-37kw
Drying Temperature :
30-85℃
Description

Product Description:

This Small Grain Dryer is a batch grain dryer that uses circulating technology for drying grains. It is made of high-quality carbon steel and provides a 1-year warranty. With a capacity ranging from 10-30t/h, it is ideal for small to medium-sized operations. Weighing 5-6t and needing 18-37kw of power, this grain dryer is both efficient and powerful. It is perfect for drying a wide range of grains, such as rice, wheat, barley, and more.

Principle:after one round of drying, the raw grains in the circulating grain dryer are not yet at the safe moisture level. The grains are then recycled into the dryer through a circulating conveying system for secondary or multiple drying. Once the dried grains reach the safe moisture level, the discharge valve is activated to discharge them from the dryer.

Features:

  • Product Name: Small Grain Dryer
  • Power: 18-37kw
  • Warranty: 1 Year
  • Drying Temperature: 30-85℃
  • Heating Method: Indirect or Direct Heating
  • Type: Batch grain dryer

Technical Parameters:

Name Parameter
Power 18-37kw
Control System One-click Intelligent Automatic Control
Warranty 1 Year
Dimension 3*3*13m
Structure Horizontal
Material Carbon Steel
Moisture Content ≤14%
Product Name Small Grain Dryer
Heating Method Indirect or Direct Heating
Fuel Coal, Gas, Diesel
Circulating Paddy Dryer Yes
Batch Paddy Dryer Yes

Features:

1. The patented technology of six impeller grain discharge ensures more uniform and thorough grain discharge.

2. Low crushing structure design for conveying equipment,.

3. One-click intelligent automatic control, touch screen operation interface, intuitive display, and easy operation.

Support and Services:

Our technical support and service team is dedicated to helping you get the most out of your small grain dryer. We provide a variety of services, including:
  • Onsite installation and commissioning
  • Regular maintenance and preventive maintenance
  • Remote technical support
  • Spare parts supply
  • User training
