OEM PM FWDM Device 1290-1500nm Transmission High Isolation Low IL Filter Wavelength Division Multiplexer for ROADM PON CWDM Systems
OEM PM FWDM Device 1290-1500nm Transmission High Isolation Low IL Filter Wavelength Division Multiplexer for ROADM PON CWDM Systems
Specifications
Place of Origin :
Guangdong , China
Brand Name :
Gracyfiber
Certification :
ISO9001 , ROHS
Delivery Time :
5-8 work days
Payment Terms :
L/C, T/T
Supply Ability :
100,000 pieces per month
Description
1. Features
  • Low Insertion Loss
  • High Isolation
  • Compact Design
  • Wide Operating Wavelength: 1260nm~1620nm
  • Wide Operating Temperature
  • High Reliability and Stability
2. Applications
  • Reconfigurable Optical Add-Drop Multiplexer (ROADM) architectures.
  • Cable Television (CATV) system infrastructure.
  • Coarse Wavelength Division Multiplexing (CWDM) networks.
  • Passive Optical Networks (PON).
3. Specifications
  • Transmission Wavelength: 1290~1500 nm.
  • Reflection/Cut-off Wavelength: 1524~1650 nm.
  • Optical Performance: Optimized for low insertion loss transmission.
  • Standards Compliance: Fully compliant with ITU-T G.694.2 and RoHS industry standards.

OEM PM FWDM Device 1290-1500nm Transmission High Isolation Low IL Filter Wavelength Division Multiplexer for ROADM PON CWDM Systems

4. Specifications
Parameters Unit Value
Transmission Wavelength nm 1290~1500
Culter Wavelength nm 1524~1650
Insertion Loss Transmission dB ≤1.0
Isolation (dB) Transmission dB ≥30
Ripple dB ≤0.4
Minimum extinction ratio (23℃) dB ≤18
Return Loss dB ≥50
Maximum Optical Input Power range mW 300
Fiber Type / Corning PM13-U25D with 0.9mm Blue Tube
Operating Temperature ℃ 0~70
Storage Temperature ℃ -40~85
Package Dimension (Φ*L) mm Φ5.5 xL38

*For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower, and ER will be 2dB lower.

5. Ordering information
PM WDM - Port Pass Channel Module type Fiber Type Output Fiber Length - COM Port Connector Pass Port Connector Reflection Port Connector
PM WDM 01=1*1 3149=1290~1500 G1~6=Glass Tube B= bare fiber 10=1.0m 00=None 00=None 00=None
02=1*2 S1~6=Steel Tube L=0.9mmtube 12=1.2m 1=FC/UPC 1=FC/UPC 1=FC/UPC
B0=90x20x10mm 02=2.0mm Tube 15=1.5m 2=FC/APC 2=FC/APC 2=FC/APC
X0= Customized 03=3.0mm Tube 3=SC/UPC 3=SC/UPC 3=SC/UPC
4=SC/APC 4=SC/APC 4=SC/APC
5=LC/UPC 5=LC/UPC 5=LC/UPC
6=LC/APC 6=LC/APC 6=LC/APC
X= Customized X= Customized X=Customized
Part Number Product Description
PMWDM-013149S6L10-22 PM FWDM Devices ,Passband 1290~1500nm, Culterband:1260~1280&1524~1650 2-Port, Steel Tube (Φ5.5*38mm),Com/Pass Fiber Length 1.0m with 0.9mm Hytrel Blue Loose Tube, Connectors: COM port FC/APC , Pass Port:FC/APC
