8CH DWDM Mux Demux Module | 1310nm Express & Monitor Port | 100GHz C-Band ITU Grid | Low IL 2.8dB | High Isolation DWDM
8CH DWDM Mux Demux Module | 1310nm Express & Monitor Port | 100GHz C-Band ITU Grid | Low IL 2.8dB | High Isolation DWDM
8CH DWDM Mux Demux Module | 1310nm Express & Monitor Port | 100GHz C-Band ITU Grid | Low IL 2.8dB | High Isolation DWDM
8CH DWDM Mux Demux Module | 1310nm Express & Monitor Port | 100GHz C-Band ITU Grid | Low IL 2.8dB | High Isolation DWDM
Specifications
Operating Wavelength :
1525~1565 nm
Channel Spacing :
100GHz (0.8nm), 200GHz (0.8nm)
Insertion Loss :
≤ 2.8 dB
Power Handling :
300 mW
Description
8CH DWDM Mux Demux Module | 1310nm Express & Monitor Port | 100GHz C-Band ITU Grid | Low IL 2.8dB | High Isolation DWDM
1. Product Overview

Gracyfiber's 8-channel dense wavelength division multiplexing (8CH DWDM) module is designed for high-capacity optical network expansion, operating at wavelengths from 1525-1565nm and integrating a 1310nm specific expansion and monitoring port.

2. Product Features
Parameter Unit Value
Operating Wavelength nm 1525~1565
Special Port nm Monitor,1310 (1260~1360)
Center Wavelength nm ITU Grid(C11 ~C64) or Customized
Channel Spacing nm 100GHz (0.8nm), 200G(0.8nm)
Channel Passband Min nm ±0.11 (100GHz), ±0.25 (200GHz),
Channel - 8CH
Port Insertion Loss Max dB 2.8
Isolation Adjacent dB ≥30
Non-adjacent dB ≥40
1310 Port Max dB 1.0
Ripple Max dB 0.5
PDL Max dB 0.5
Return Loss Min dB 40
Directivity Min dB 50
Power Handing Max mW 300
Fiber Type - G67A1/ A2/ B3 or SMF-28
Fiber Coating um 250 µm / 900 µm loose tube
Fiber Length mm 1000
Connector - LC/UPC or Customized
Dimensions (HxWxD) mm 80x58x8, 120x80x18, 155x129x29, 482x250x44
Operating Temperature °C -5~65
Storage Temperature °C -40~85
  • 8-channel C-band operating wavelength (1525~1565nm)
  • Integrated 1310nm specific expansion/monitoring port
  • Supports 100GHz and 200GHz ITU mesh
  • Low port insertion loss (≤ 2.8 dB)
  • High isolation between adjacent and non-adjacent channels (≥ 30 dB / ≥ 40 dB)
  • High return loss (≥ 40 dB) and high directivity (≥ 50 dB)
  • Maximum 300mW optical power carrying capacity
  • Multiple high-reliability box/rack-mount packaging options

8CH DWDM Mux Demux Module | 1310nm Express & Monitor Port | 100GHz C-Band ITU Grid | Low IL 2.8dB | High Isolation DWDM

3. Applications
  • Dense wavelength division multiplexing (DWDM) system expansion
  • Long-haul trunk and metropolitan area network (MAN) transmission
  • Optical add-drop multiplexer (OADM) nodes
  • Data center interconnect (DCI) and enterprise leased lines
  • Multi-service transmission platform (MSTP) integration
