8CH MWDM Mux Module 1271.5–1341.5nm 10nm Spacing Low Insertion Loss FC UPC 100×80×10mm ABS Box
8CH MWDM Mux Module 1271.5–1341.5nm 10nm Spacing Low Insertion Loss FC UPC 100×80×10mm ABS Box
8CH MWDM Mux Module 1271.5–1341.5nm 10nm Spacing Low Insertion Loss FC UPC 100×80×10mm ABS Box
8CH MWDM Mux Module 1271.5–1341.5nm 10nm Spacing Low Insertion Loss FC UPC 100×80×10mm ABS Box
Specifications
Channel Spacing :
10nm
Insertion Loss :
≤ 3.0dB
Operating Temperature :
-5 ~ +75°C
Model Number :
953111419
Wavelength Range :
1260~1380nm
Description
8CH MWDM Mux Module 1271.5–1341.5nm 10nm Spacing Low Insertion Loss FC UPC 100*80*10mm ABS Box
1. Product Overview

This 8-channel MWDM multiplexer module covers a wavelength range of 1271.5–1341.5nm, combining eight optical signals into a common port with 10nm spacing.

2. Product Features
Testing Data Sheet
Product Name: 8CH MWDM, 1271.5/1281.5/1291.5/1301.5/1311.5/1321.5/1331.5/1341.5nm , 100x80x10 Module with FC/UPC ,1.0±0.03m
P/N: MWDM-1x8-M-1271.5/1281.5/1291.5/1301.5/1311.5/1321.5/1331.5/1341.5-09-10-100*80*10-FC/UPC
S/N: M20260806004
Date: 2026/8/6
Testing Data
Parameter Units Value
Wavelength Range nm 1260~1380
Operating Wavelength nm 1271.5 1281.5 1291.5 1301.5 1311.5 1321.5 1331.5 1341.5
Insertion Loss dB 0.59 0.76 0.88 1.05 1.28 1.42 1.38 1.59
Isoation Adjacent dB ≥25
Isoation Non-Adjacent dB ≥35
Ripple dB ≤0.5
Directivity dB >50
Return Loss dB >45
PDL dB ≤0.1
PMD ps ≤0.10
Connectors / FC/UPC
Fiber Type / 0.9mm loose tube ,G657A1
Fiber Length m 1±0.03
Power Handing(mW) mW 300
Operating Temperature °C -5 ~ +75
Storage Temperature °C -40 ~ +85
Dimensions (LxWxH) mm 100x80x10
* testing data include connectors
Test By:
  • 8-channel MWDM multiplexer design
  • Channel wavelengths: 1271.5, 1281.5, 1291.5, 1301.5, 1311.5, 1321.5, 1331.5, 1341.5nm
  • Channel spacing: 10nm
  • 0.5dB passband width: ±3nm
  • Insertion loss IL ≤ 3.0dB
  • Passband ripple ≤ 0.5dB
  • Adjacent channel isolation > 25d B. Non-adjacent channel isolation > 35dB; Return loss RL ≥ 45dB; Directivity DIR ≥ 50dB; Polarization dependent loss PDL ≤ 0.1dB; Polarization mode dispersion (PMD) ≤ 0.1ps; Maximum optical power handling ≤ 300mW; Uses SMF-28e single-mode fiber; Contains 0.9mm white loose tube; Fiber length including connectors: 100±3cm; All ports are equipped with FC/UPC connectors; Fiber optic cable size: 100*80*10mm. ABS box-type packaging
  • Operating temperature range: -5～+75℃
  • Storage temperature range: -40～+85℃
  • Connectors undergo 100% 3D interference testing and end-face appearance inspection
  • UPC end-face key control: vertex offset, fiber height, and radius of curvature
  • Defects are not allowed in end-face area A; the number of minor defects in area B is controlled according to regulations.
  • Supports customization of channel combinations, fiber types, lengths, connectors, and packaging.
3. Applications
  • 5G mobile fronthaul network
  • MWDM wavelength division multiplexing transmission system
  • Fiber optic link capacity expansion
  • Multi-wavelength signal multiplexing transmission
  • Base station BBU, RRU, and AAU interconnection
  • Metropolitan area network and access network
  • Optical network monitoring and testing system
  • Optical communication equipment and module integration
