Specifications
Place of Origin :
China
Brand Name :
Topshine(Support OEM/ODM)
Model Number :
MT100
Certification :
ce, RoHS
Packaging Details :
Neutral color or white box(22*16.5*5.5cm), Unit weight: 0.28Kg, 32 units/Carton
Price :
$67.00/Pieces
MOQ :
1piece
Payment Terms :
T/T, Western Union, MoneyGram,paypal
Supply Ability :
100000pcs/month
Delivery Time :
1-8 work days
Function :
Remote Control, Distance Warning, Speed Warning, Build-in Microphone, Real time gps tracking, RFID car alarm
Connection :
2G/4G Sim Card, RS232 port
Warranty :
2 years
Software :
Free tracking software
GSM module :
Legal IMEI &CE
Fingerprint reader :
Car alarm and driver identify
Battery capacity :
450mAh Li-ion Battery
Data logger :
4MB memory
Engine on alarm :
Support
Detect fuel consumption :
Support
OTA function :
Support
Description
GPS tracker MT100 is a kind of mini GPS vehicle tracking product can be used for tracking andsecurity of motorcycle and automobile etc. Mini size, built-in antenna and waterproof designed, easy to be installed and concealed, with power voltage range from 9V~36V, therefore can satisfy tracking and security demands for all kinds of vehicles.
Tracker MT100 can work with fingerprint reader to achieve smart car alarm and driver identify, it also will generate one driver report on the gps tracking platform.
What is smart car alarm?
Unauthority fingerprint cant drive the vehicle. Once tracker identify unauthority fingerprint, it will trigger relay to cut off
engine automatically, send SMS alarm and call to administrator, also trigger siren to sound. (For fleet management)
What is driver/student ID identify?
Tracker can identify 100 fingerprints, when driver put their fingerprint on the reader, tracker will upload this fingerprint
number to GPRS tracking platform, then generate driver / student report.
Features
* 2G/4G network GPS tracker
* Tracking by SMS/GPRS (TCP/UDP)
* Tracking by time/distance interval
* OTA Function
* Real time tracking via the web-platform
* Get position location via call/SMS
* Engine on/off detection
* Built-in backup 450mAh battery
* Remote Engine cut off to stop the car in safe condition
* ARM9 high speed micro-controller
* Get location physical name via SMS & from the web-platform
* Google Map link for location via SMS, it shows your location on map via mobile phone.
* Mileage calculation with longitude and latitude via SMS; view mileage data via GPS web-based tracking centre system
* Built-in motion sensor for power & GPRS flow saving mode (sleep mode)
* Built-in 4MB memory & position logging capacity up to 26,000+ way-points even no GPRS signal
* I/O: 3 Inputs, 2 Outputs, 1 Analog Input, 1 RS232 port
Alerts & optional features
* Over speed alert
* Geo-fence alert
* Engine on alert (Optional)
* Power failure/low power alert (Optional)
* SOS Panic button, SOS alert (optional)
* Harsh braking and harsh acceleration alarm
* Oil leaking/Refuel Alarm (need fuel sensor support) (optional)
* Accident alarm (need crash sensor support) (optional)
* Two way communication (Speaker and microphone) (Optional)
* RS232 Port Can equip with RFID kit for driver identification and auto Arm/Disarm functions (movement/towed alert, ignition alert, auto cut off engine etc) (need RFID support) (optional)
* Analog input for Fuel sensor detecting/monitoring (optional)
* Customize output4 wire (optional)
* Customize input5 wire for detecting Air condition ON or OFF..etc, it is positive trigger (optional)
* Customize second Analog port (like detecting second fuel tank)(optional)
* Customize dual serial port that can support RFID reader and temperature sensor (or OBDII connector) at the same time(optional)
* Detecting the voltage of car battery (optional)

MT100 36V Tracking Device Motorcycle GPS Tracker With Fingerprint Identify System
MT100 36V Tracking Device Motorcycle GPS Tracker With Fingerprint Identify System
Product Name
GPS tracker MT100
Dimension
80* 58* 22MM
Weight
92G
Input voltage
DC 9V~36V/1.5A
Back-up Battery
450mAh/3.7V
Power Consumption
65mA standby current
Memory
4M Byte data logger
CPU
ARM9 high speed micro-controller
Operating Temperature
-40°C~75°C
Humidity
5%~95%
LED
2 LED lights to show GPS, GSM status
Button
1 SOS and 1 power on/off
2G GSM frequency
GSM 850/900/1800/1900MHz
4G GSM frequency
LTE-FDD B1/B3/B5/B8
B1/B3/B5/B7/B8/B20/B28
LTE-TDD B34/B38/B39/B40/B41
B38/B40/B41
GSM B3/B8 B2/B3/B5/B8
GPS Sensitivity
-160dBm
Positioning Accuracy
5meters, CEP
I/O

3 Input, 2 Output, 1 Analog input

(Support cutomize more input/output/analog)
GPS Tracking Platform
Topshine company provide free tracking platform to clients, no any monthly or yearly charge.
Web: www.track-car.com

Mobile link: www.track-car.com/m

Usernam: officetest1

Password: 123
MT100 36V Tracking Device Motorcycle GPS Tracker With Fingerprint Identify System
Log in page
Replay
MT100 36V Tracking Device Motorcycle GPS Tracker With Fingerprint Identify System
Multi reports
Product Usage

Standard accessories
1 main unit MT100
1 wiring
1 12v/24v relay
1 SOS button
1 built in battery

  • Optional accessories

Ultrasonic fuel sensor
Cuttable fuel sensor
OBDii connector
Passive RFID reader & tag
Active RFID reader & tag
Temperature sensor
Crash sensor
Speed limiter
Microphone
Speaker
Siren
Configure USB cable
Our Service
1. Any inquiries will be replied within 12 hours on workday.

2. Professional manuafacurer and wholesaler for 10 years.

3. OEM available:
* Customized logo or color box
* We can help you to design and put it into production about your idear

4. After-sale service:
* All products will have been strictly Quality checked in workshop before packing
* All our products have 24 mouths warranty, and we are sure our products will be free from maintenance

5. Shipping way: DHL/UPS/Aramex/fedex/air transportation/sea transportation

6. Fast delivery: Sample order in stock; 10~100pcs: 2~3 days; 3~7 days for bulk order

7. Payment: T/T , Western Union, Paypa, ali insurance and RMB

Why Choose Us
♦ Professional manufacturer, less intermediate links, then more competitive price and quicker service than a trade company.
♦ 10 year experience in GPS tracking system and car alarm security system, strict ISO9001 quality control and rigorous tests before shipment,ensures our superior and proven reliable quality. Tests include high and low temperature aging test, vibration test, noise tests, high and low voltage change tolerance test, etc.
♦ Top R&D team for GPRS, GSM, system integration etc. let it possible for us to supply professional solutions, quick support andmeet with your special and complicated requirements in short time.
♦ Easy to use Free online worldwide tracking platform on our server, you can track and monitor live data or view historical data totally free on our web server, without any monthly charges.
♦ 90% turnover for exporting, with experience for global markets.
♦ Customization/OEM/ODM/Buyer’s labeling service is welcomed.
