168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Youwei
Model Number :
168G3
MOQ :
1
Price :
$5-7
Power Supply :
5V
Baud Rate :
9,600 bps
Channel Count :
66
Maximum Velocity :
515 m/s
Positioning Accuracy :
<2.5m average
Cold Start Time :
29 seconds
Warm Start Time :
28 seconds
Hot Start Time :
1 second
Tracking Sensitivity :
-161dBm
Reacquisition Sensitivity :
-160dBm
Cold Start Sensitivity :
-147dBm
Maximum Altitude :
50,000 meter
Timepulse Signal :
RMS 30 ns
Navigation Update Rate :
1 Hz
Frequency Band :
L1
Description
Product Description

168G3 GPS Mouse Antenna Receiver Product Features:

l DC Power 5V

l Real-time positioning & tracking with playback capability

l Ultra-compact form factor

l Plug-and-play installation (auto-power on without button)

l Built-in backup coin cell battery (maintains data during power loss)

l Triple-mode positioning: GPS + BeiDou + GLONASS

Product Parameters:

Item

Specification

Chip

MediaTek GK9051 (Rom Version)

Frequency

L1 frequency band

Code

C/A Code

Protocol

NMEA 0183 v4.1
GALILEO L1 open service (with upgrade)
Default: GGA,GSA,GSV,RMC
Support: VTG,GLL,TXT ublox binary and NMEA Command

Available Baud Rate

9,600 bps

Channels

66

Sensitivity

Tracking: -161dBm
Reacquisition: -160dBm
Cold Start: -147dBm

Cold Start

29 seconds, average

Warm Start

28 seconds, average

Hot Start

1 second, average

Accuracy

Horizontal Position: Autonomous <2.5m average,
SBAS < 2.0m average
Velocity: 0.1 m/s
Timepulse signal: RMS 30 ns

Maximum Altitude

50,000 meter

Maximum Velocity

515 m/s (1000 knots)

Dynamics

4G

Max navigation update rate

1 Hz (Default 1Hz)

Product Picture

168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS168G3 Mini GPS Receiver with 96H Battery Life GPS BDS GLONASS
