High Precision Optical Test Instruments JZ3208 Optical Power Meter Compact Size
High Precision Optical Test Instruments JZ3208 Optical Power Meter Compact Size
Specifications
Model Number :
JZ3208
Place of Origin :
Shenzhen, China
MOQ :
10pcs
Payment Terms :
T/T, L/C
Delivery Time :
10-15 working days
Packaging Details :
Standard Carton
name :
fiber optic power meter
Description

High Precision Optical Test Instruments JZ3208 Optical Power Meter Compact Size

● High performance handheld optical power meter can meet high precision power measurement of fiber signal.
● It can be used for the absolute power measurement and relative measurement of the link loss in dB.
● Its compact size
● Friendly operation interface
● Wide power measurement range
● High precision measurement
● Advanced user calibration function
● Unique design for universal FC/SC/ST optical connector
● High performance in application makes it an ideal tool for optical fiber network operation.

Specifications:

Model

JZ3208
Wavelength Range(nm)*1 800~1700
Detector Type InGaAs
Measurement Range(dBm)*2 -50~+26
Uncertainty *3 ±0.25dB
Accuracy 0.01dBm
Operating Temperature(℃) -10~+60
Storage Temperature(℃) -25~+70
Auto-off Time(min) 10
Operating Time(h) ≥130
Battery 3 AA1.5V
Weight(g) 160
Dimensions(mm) 152X74X26

Notes:
*1 Wavelength Range: Specified standard operating wavelength range in which the Power Meter can work properly under certain technical specifications.
*2 Power Measurement Range: The maximum and minimum range in which the Power Meter can work properly.
*3 Uncertainty: Difference between two measurement results that were tested by Power Meter and another Standard Power Meter respectively.
