Specifications
Brand Name :
Global Power
Model Number :
GPLTY-1000*4
Certification :
ISO/CQC
Place of Origin :
Jiangsu, China
MOQ :
3sets
Price :
Negociable
Supply Ability :
2000sets /year
Delivery Time :
20 days
Packaging Details :
Plastic Foam or Plywood Pallet
Key Words :
Lighting Tower Portable Diesel Generator Set
Stroke :
Four Stroke
Landuse Type of Unit :
Low Noise, Soundproof
Alternator insulation :
H
Excitation Mode :
Capacity exciter
Protection grade :
IP23
Cooling system :
Water-cooled
Mast height :
8m
Mast Operated System :
Manual (Electric optional)
Voltage :
110V, 120V, 220V, 230V, 240V
Protection glass :
IP33
Description

GPLTY-1000*4

Light Tower Diesel Power Generator Set Ratings

Model GPLTY-1000*4
Rated frequency Hz 50
Rated power KW 6
Max. power KW 7
Working dimension mm 2990x1300x8000
Weight Kg 800

Contruction Emergency Portable 6-7kw 50Hz Mobile Light Tower , Trailer Mounted Light TowersContruction Emergency Portable 6-7kw 50Hz Mobile Light Tower , Trailer Mounted Light Towers

Relied on its high reliability, maximum safety, easy operation and simple maintenance etc., light towers are suitable for varies applications like construction site, mining filed, rental business, public equipment service, accident handling, large-scale event, disaster relief etc.

Engine
Engine brand
Engine model LD380
Speed 1500/1800 rpm
Prime power 12/14.4kw
Cooling system Water-cooled
Oil capacity 4.5L

Alternator
Alternator brand
Alternator model LA130/4
Continued power 7/8kVA
Excitation mode Capacity exciter
Alternator insulation H
Protection grade IP23

Mast
Mast type Manual
Mast height 8m
Section no. (extended) 4
Mast rotation 359°
Mast extension time 45s
Mast descend time 30s

Lighting
Type of ligths Metal halide lamp
Number & Power of lights 4x1000w
Mast lighting & Extension Manual operation (Electric optional)
Light angle turning Manual
Luminous flux 4x110000=440000
Illum area (5 Lux min) 3900m²
Lamps rotation 75°(automatic)
Protection glass IP33
Color temperature 4200k

Trailer
Manufacture
Braking system /
Hitch Ball type / O ring optional
Tire number 2
Tire rim size 165 / 14”
Speed <80km/h

Light tower standard and optional features:

Generator set:

  • Soundproof diesel generator set
  • Watertight digital panel, for control, protection managing
  • 1 auxiliary power sockets
  • 1 supply auxiliary entry
  • External filling of the fuel tank
  • Emergency stop
  • Wide accesses for maintenance
  • Lifting ring and forklift pockets
  • Oil & Coolant drains for service ability
  • Independent circuit breakers
  • Engine block heaters (Optional)
  • Spark arrestor (Optional)
  • Ground connection (Optional)

Mast:

  • Manual mast
  • Manual winch
  • Double safety block: mast height blocking & trailer blocking
  • Electric mast (Optional)
  • Electric winch (Optional)

Trailer:

  • 4 heavy duty stabilizers with level bubble
  • 2*165 / 14” tires
  • Mudguard
  • Transport kit

Lighting:

  • 4*1000W metal halide lamps
  • 4*350W LED lamps (Optional)

Benefits:

  • Kubota / Lees / Perkins engines to provide reliable power and high performance.
  • Standard design and personal modification ensure to offer the project at the fastest speed.
  • Telescopic, mechanical, 4 stages mast up to 8 meters
  • New unique high pressure aluminum lamps
  • Heavy-duty winch design and integral forklift pockets.
  • High frequency generator work without ballast, easy to maintain
  • Hydraulic/Manual winch for extending and retracting mast.
  • Separate steel doors, lockable, weather protected and powder-coated protection
  • Individual breaker switch for each light assembly
  • Auxiliary big fuel tank
  • Safe and quick installation
