12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage
Specifications
Brand Name :
GOORUI VACUUM PUMP
Model Number :
GHBH 017 36 AR9
Certification :
CE/TUV/ISO9001-2001/SGS/ROHS
Place of Origin :
MADE IN CHINA
MOQ :
1
Price :
$1435.00/set
Payment Terms :
T/T, L/C, D/A, D/P, Western Union,
Supply Ability :
1000 set/day
Delivery Time :
15 work days
Packaging Details :
1. Packed in individual cartons.
Model No :
GHBH 017 36 AR9
Phase :
3
Stage :
single
Frequency :
50/60HZ
Output :
12.5kw/14.5kw
Voltage :
345-415△600-690Y/380-480△660-720Y
Current :
28.0△/16.2Y/29.0△/16.7Y
Max Airflow :
1370m3/h/1650m3/h
Max Vacuum :
190mbar/150mbar
Max Pressure :
180mbar/150mbar
Gloss Weight :
121kgs
Speed of rotation :
2850/3450r/min
Sound :
75/80db
Level of protection :
IP54
Insulation class :
F
Color :
Golden or Silver
Description

12.5 kw 14.5 kw pneumatic conveying air pump side channel blower Vacuum pump

Goorui Model Single Frequency Rated Voltage Rated Max Rated Rated Sound Weight
Double Output Current Airflow Vacuum Pressure
Stage Hz KW V A m3/h mbar mbar dB(A) Kg
GHBH 017 36 AR9 Single 50 12.5 345-415△600-690Y 28.0△/16.2Y 1370 -190 180 75 121
60 14.5 380-480△660-720Y 29.0△/16.7Y 1650 -150 150 80

12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage

Goorui Bower feathers and advantages :

  • Oil free and low noise

  • No routine maintenance with stable performance

  • Easy install and no vibration

  • SKF , NSK , ORS bearing adapt to ensure long-life time

  • Either used for suction ( vacuum ) or discharge ( pressure )

  • Insulation class: F, Protection class: IP54

Product Description

OVER 200 DESIGNS IN DIFFERENCE WORKING PERFORMANCE

In 2008,Successfully design and produce the ultra high pressure blowers.

In 2011,Successfully design and produce the explosion-proof side channel blower

12.5 Kw 14.5 Kw Regenerative Vacuum Pump For Pneumatic Conveying Single Stage

Based on clients' requirements,Goorui design the special models suce as Anti-Corrosion blower,Anti-Explosion blower,dusk-free blower,Water-Cooling blower etc....to help solve clients' problem.

Application:Anti-explosion blwers are mainy used in explosive atmosphere environment.

GOORUI Special Customized Series

Goorui not merely providing a high pressure blower but also the whole solution to solve the vacuum problems.
