P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
Specifications
Color Temperature :
8500-9500K
warranty :
1 Year
Operating Temperature :
-10℃~40℃
Resolution :
256 dots(W)* 128 dots(H)
Waterproof :
IP30
Viewing Angle :
160±10°
Power Consumption :
≤ 25W
Refresh Rate :
3840HZ
Mounting options :
wall mount, ceiling mount, Floor stand, Custom Mount
Power Supply :
100-240v AC 50-60Hz
Content Management System :
Yes
Sunlight Readable :
Yes
Remote Device Management :
YES
type :
LED
brand name :
Googol
application :
indoor
use :
advertising publish, retail store, shopping mall, display of dishes, welcome display, self-service business, exhibition hall, wayfinding, airport, subway, elevator, Restaurant & Hotel Supplies, Education, medical treatment
media available :
Photo, datasheet, Other, EDA/CAD Models
color :
RGB
model number :
P1.25
pixel density :
640000Dots/square meter
place of origin :
ShenZhen,China
pixels :
P1.25
Brightness :
≥500cd/square meter
Lamp tube packaging :
SMD1010Matte black light
Module size(L*W*H) :
320*160*16.4mm
Weight :
0.5kg
Optimum viewing distance :
1M~10M
Lifespan :
≥100000hours
Working voltage :
4.2~5V
Scanning mode :
1/64scan
Interface means :
HUB320
Drive mode :
Constant Current Driving
Refresh rate :
≥3840HZ, high refresh rate
MOQ :
6 pieces
Price :
$326/pieces >=6 pieces
Description
IP1.25 indoor full-color high-refresh rate LED module
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
product feature.
With 1.25mm ultra-small dot pitch, ultra-high resolution is achieved indoors, presenting an amazing high-definition image effect. With a wide viewing angle, the colors are still real and gorgeous no matter you look from top to bottom, left to right, meeting the needs of viewing from different angles.
With three-in-one LED, RGB color mixing effect is good, making the color performance more vivid and the image more realistic. The screen occupies a small volume, the box is light, and the indoor high-density full-color screen displays delicate and realistic images. The surface mount packaging technology, uniformity, brightness, and viewing angle are good, and quick installation and disassembly are achieved, saving your valuable time and labor costs.
Nmber
Technical Project details
specification parameter
1
Module size
320*160*16.4mm
2
Pixel pitch
1.25mm
3
Pixel density
640000 dots/square meter
4
The color of the luminous point
1R1G1B
5
LED packaging
SMD1010Matte black light
6
Working voltage
4.2~5V
7
Module weight
0.5KG
8
Drive mode
Constant Current Driving
9
Scan mode
1/64 scan
10
Interface means
HUB320
11
White balance brightness
≥500cd/square meter
12
Color mark seat temperature
XY0.28~0.30
13
Color temperature
8500-9500K
14
Refresh rate
≥3840HZ，HD
15
Connector
1U gold-plated connector, no ribbon cable connection inside the box
16
Drive and Control
Dedicated 12BIT high grayscale, high refresh drive constant current IC, unique blanking circuit to protect LED and prevent surge leakage
17
Application scope
Halls of government buildings, halls of enterprises and institutions, conference rooms, exhibition halls, commercial buildings,
stages, party venues, etc.
18
Storage temperature
-30~60℃
Product packaging
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
P1.25 SMD1010 RGB LED Module 320x160mm 1/64 Scan
The packaging uses high-quality cartons, and the modules are equipped with corner protectors containing pearl cotton corner protectors to effectively prevent product damage caused by collisions during handling and transportation.
