Specifications
Brand Name :
Gen-song
Model Number :
Three-way forklift FMR
MOQ :
1
Price :
US $4200.00 - 5500.00/ Set
Payment Terms :
T/T
Supply Ability :
200 sets per year
Delivery Time :
90 days
Packaging Details :
As required
Fork Length :
1220 mm
Working time :
4-6H
Lifting speed (laden) :
180 mm/s
Navigation position accuracy :
±10 mm
Forklift Turning radius :
2240 mm
Load centre distance :
600 mm
Travel speed ( laden) :
1.0 m/s
Description
Gen-song Three-Way VNA Forklift FMR Series

The truck that lets you store 1000×1200 mm pallets in 1550–1600 mm aisles — for real

Why Everyone in China Uses This Truck

Forget the “1.6 m” on paper. Most imported three-way trucks need at least 1.8–1.9 m to actually turn the forks with a 1200 mm pallet. The Chinese FMR series can do it in 1550–1600 mm every day. The forks rotate 180° inside the wheelbase and the cabin lifts with the forks, so the driver always looks straight at the pallet even at 14 m height. Thousands are running in cold stores, pharma warehouses and spare-parts centers right now.

Real-World Advantages
  • 1550–1600 mm actual working aisle (1000×1200 mm pallet long-side pick)
  • Cabin goes up with forks – driver never has to look up
  • Standard side-shift left/right 800 mm – makes placing perfect
  • Full AC motors – no carbon brushes to change
  • Imported German mast rails – smooth and quiet even at 15 m
  • Cold store version down to -30 °C with heated cabin
Main Specs
Capacity 1.0 – 1.6 ton
Lift height 4.5 – 15 m
Real aisle width 1550–1600 mm
Battery 48V 400–700 Ah
Fork rotation 180° continuous
Side-shift ±400 mm each side (800 mm total)
Travel speed 10 km/h
Where They Work Every Day
  • Cold storage (-25 °C)
  • Pharmaceutical distribution centers
  • Auto parts high-bay warehouses
  • Tobacco and liquor warehouses
Questions Customers Always Ask

Q: Is 1.55 m really possible?
A: Yes – come see our demo warehouse in Hangzhou, trucks running 1.55 m aisles all day.

Q: How is the mast so quiet?
A: German rails + imported chain, no cheap Chinese rails.

Q: Spare parts?
A: 24-hour delivery in China, overseas stock in Dubai and Rotterdam.

Contact Us

Phone/WhatsApp/WeChat: +8615000725058
Email: edwardzhao@gbsxj.com

Other Trucks We Sell
  • FMR 2.0 ton version
  • Double-deep three-way truck
  • Four-direction forklift
