Specifications
Customized support :
OEM, ODM
Place of Origin :
Beijing, China
Brand Name :
Golden
Model Number :
GL11-VIS-K9
Supply Ability :
1000 Piece/Pieces per Month
MOQ :
200.0 Pieces
Description
Golden Plano Optical Glass Magnifying Convex Lens For Projector
Golden Plano Optical Glass Magnifying Convex Lens For Projector
Product Specification
A plano-convex lens has a convex surface and a flat surface, and has a positive focal length. It is usually used for related applications such as reducing the beam, reducing the focal length, or enlarging the image. In order to reduce the spherical aberration, when the plano-convex lens is used to collimate the beam, the beam should be incident on the curved surface of the lens; when used for the collimation of the point light source, the beam should be incident on the plane. Optotech provides plano-convex lenses without coating and anti-reflection coating. Antireflection coating options include UV, VIS, NIR, and SWIR. Germanium, silicon, or zinc selenide substrates are suitable for infrared applications, and fused silica is suitable for ultraviolet applications.
GL11-K9 Plano-Convex Lens (Visible Broadband Anti-Reflection Coating)
Product number
Diameter
Center thickness
Edge thickness
radius
focal length
Coating requirements
D(mm)
Tc(mm)
Te(mm)
R(mm)
EFL(mm)
BBAR-01
GL11-003-004-VIS
3.00
1.70
1.15
2.33
4.50
Ravg<0.5% @400~700nm
GL11-003-010-VIS
3.00
1.70
1.48
5.17
10.00
Ravg<0.5% @400~700nm
GL11-004-005-VIS
4.00
1.90
0.95
2.58
5.00
Ravg<0.5% @400~700nm
GL11-004-006-VIS
4.00
1.70
1.01
3.25
6.30
Ravg<0.5% @400~700nm
GL11-004-010-VIS
4.00
1.70
1.30
5.17
10.00
Ravg<0.5% @400~700nm
GL11-005-008-VIS
5.00
1.50
0.66
4.13
8.00
Ravg<0.5% @400~700nm
GL11-006-008-VIS
6.30
2.60
1.14
4.13
8.00
Ravg<0.5% @400~700nm
GL11-006-010-VIS
6.30
2.60
1.53
5.17
10.00
Ravg<0.5% @400~700nm
GL11-006-012-VIS
6.30
2.30
1.48
6.46
12.50
Ravg<0.5% @400~700nm
GL11-006-016-VIS
6.30
2.10
1.48
8.26
16.00
Ravg<0.5% @400~700nm
GL11-006-020-VIS
6.30
2.00
1.51
10.36
20.00
Ravg<0.5% @400~700nm
GL11-006-025-VIS
6.30
1.90
1.51
12.91
25.00
Ravg<0.5% @400~700nm
GL11-006-040-VIS
6.30
1.70
1.46
20.65
40.00
Ravg<0.5% @400~700nm
GL11-006-063-VIS
6.30
1.70
1.55
32.50
63.00
Ravg<0.5% @400~700nm
GL11-010-012-VIS
10.00
3.90
1.53
6.46
12.50
Ravg<0.5% @400~700nm
GL11-010-016-VIS
10.00
3.20
1.52
8.26
16.00
Ravg<0.5% @400~700nm
GL11-010-020-VIS
10.00
2.80
1.51
10.36
20.00
Ravg<0.5% @400~700nm
GL11-010-025-VIS
10.00
2.50
1.49
12.91
25.00
Ravg<0.5% @400~700nm
GL11-010-032-VIS
10.00
2.30
1.51
16.27
31.50
Ravg<0.5% @400~700nm
GL11-010-040-VIS
10.00
2.10
1.49
20.65
40.00
Ravg<0.5% @400~700nm
GL11-010-050-VIS
10.00
2.00
1.51
25.84
50.00
Ravg<0.5% @400~700nm
GL11-010-063-VIS
10.00
1.90
1.51
32.50
63.00
Ravg<0.5% @400~700nm
GL11-010-100-VIS
10.00
1.70
1.46
51.64
100.00
Ravg<0.5% @400~700nm
GL11-012-020-VIS
12.00
3.00
1.12
10.50
20.30
Ravg<0.5% @400~700nm
GL11-015-060-VIS
15.00
2.30
1.38
31.02
60.00
Ravg<0.5% @400~700nm
GL11-016-020-VIS
16.00
4.80
1.02
10.36
20.00
Ravg<0.5% @400~700nm
GL11-016-025-VIS
16.00
4.00
1.22
12.91
25.00
Ravg<0.5% @400~700nm
GL11-016-032-VIS
16.00
3.60
1.50
16.27
31.50
Ravg<0.5% @400~700nm
GL11-016-040-VIS
16.00
3.10
1.49
20.65
40.00
Ravg<0.5% @400~700nm
GL11-016-050-VIS
16.00
2.80
1.53
25.84
50.00
Ravg<0.5% @400~700nm
GL11-016-063-VIS
16.00
2.50
1.50
32.50
63.00
Ravg<0.5% @400~700nm
GL11-016-080-VIS
16.00
2.30
1.52
41.30
80.00
Ravg<0.5% @400~700nm
GL11-016-100-VIS
16.00
2.10
1.48
51.64
100.00
Ravg<0.5% @400~700nm
GL11-016-160-VIS
16.00
1.90
1.51
82.62
160.00
Ravg<0.5% @400~700nm
GL11-020-030-VIS
20.00
4.50
0.84
15.50
30.00
Ravg<0.5% @400~700nm
GL11-020-050-VIS
20.00
4.20
2.19
25.84
50.00
Ravg<0.5% @400~700nm
GL11-025-025-VIS
25.00
11.16
2.00
13.11
25.40
Ravg<0.5% @400~700nm
GL11-025-027-VIS
25.00
9.50
1.55
13.80
26.70
Ravg<0.5% @400~700nm
GL11-025-032-VIS
25.00
7.86
2.00
16.27
31.50
Ravg<0.5% @400~700nm
GL11-025-040-VIS
25.00
6.21
2.00
20.65
40.00
Ravg<0.5% @400~700nm
GL11-025-050-VIS
25.00
4.70
1.47
25.84
50.00
Ravg<0.5% @400~700nm
GL11-025-063-VIS
25.00
4.00
1.50
32.50
63.00
Ravg<0.5% @400~700nm
GL11-025-076-VIS
25.00
3.60
1.56
39.28
76.00
Ravg<0.5% @400~700nm
GL11-025-080-VIS
25.00
3.94
2.00
41.30
80.00
Ravg<0.5% @400~700nm
GL11-025-100-VIS
25.00
3.54
2.00
51.64
100.00
Ravg<0.5% @400~700nm
GL11-025-125-VIS
25.00
3.22
2.00
64.55
125.00
Ravg<0.5% @400~700nm
GL11-025-160-VIS
25.00
2.95
2.00
82.62
160.00
Ravg<0.5% @400~700nm
GL11-025-200-VIS
25.00
2.76
2.00
103.28
200.00
Ravg<0.5% @400~700nm
GL11-025-250-VIS
25.00
2.61
2.00
129.24
250.00
Ravg<0.5% @400~700nm
GL11-025-315-VIS
25.00
2.00
1.50
162.79
315.00
Ravg<0.5% @400~700nm
GL11-025-400-VIS
25.00
2.38
2.00
206.10
400.00
Ravg<0.5% @400~700nm
GL11-025-500-VIS
25.00
2.30
2.00
258.18
500.00
Ravg<0.5% @400~700nm
GL11-025-630-VIS
25.00
1.78
1.54
325.58
630.00
Ravg<0.5% @400~700nm
GL11-025-800-VIS
25.00
1.70
1.50
413.44
800.00
Ravg<0.5% @400~700nm
GL11-025-1000-VIS
25.00
2.15
2.00
516.50
1000.00
Ravg<0.5% @400~700nm
GL11-025-1600-VIS
25.00
2.09
2.00
826.88
1600.00
Ravg<0.5% @400~700nm
GL11-025-2000-VIS
25.00
2.04
2.00
1033.60
2000.00
Ravg<0.5% @400~700nm
GL11-025-2500-VIS
25.00
2.03
2.00
1292.00
2500.00
Ravg<0.5% @400~700nm
GL11-040-040-VIS
40.00
17.95
2.50
20.67
40.00
Ravg<0.5% @400~700nm
GL11-040-050-VIS
40.00
11.98
2.50
25.84
50.00
Ravg<0.5% @400~700nm
GL11-040-063-VIS
40.00
9.38
2.50
32.50
63.00
Ravg<0.5% @400~700nm
GL11-040-080-VIS
40.00
7.67
2.50
41.30
80.00
Ravg<0.5% @400~700nm
GL11-040-100-VIS
40.00
6.53
2.50
51.64
100.00
Ravg<0.5% @400~700nm
GL11-040-125-VIS
40.00
5.68
2.50
64.55
125.00
Ravg<0.5% @400~700nm
GL11-040-160-VIS
40.00
4.96
2.50
82.62
160.00
Ravg<0.5% @400~700nm
GL11-040-200-VIS
40.00
4.45
2.50
103.28
200.00
Ravg<0.5% @400~700nm
GL11-040-250-VIS
40.00
4.06
2.50
129.24
250.00
Ravg<0.5% @400~700nm
GL11-040-500-VIS
40.00
3.28
2.50
258.18
500.00
Ravg<0.5% @400~700nm
GL11-045-100-VIS
45.00
6.10
0.97
51.90
100.00
Ravg<0.5% @400~700nm
GL11-045-120-VIS
45.00
6.10
1.89
62.20
120.00
Ravg<0.5% @400~700nm
GL11-050-063-VIS
50.00
14.73
3.00
32.50
63.00
Ravg<0.5% @400~700nm
GL11-050-080-VIS
50.00
11.43
3.00
41.30
80.00
Ravg<0.5% @400~700nm
GL11-050-100-VIS
50.00
9.45
3.00
51.64
100.00
Ravg<0.5% @400~700nm
GL11-050-160-VIS
50.00
6.87
3.00
82.62
160.00
Ravg<0.5% @400~700nm
GL11-050-250-VIS
50.00
5.44
3.00
129.24
250.00
Ravg<0.5% @400~700nm
GL11-050-500-VIS
50.00
4.21
3.00
258.18
500.00
Ravg<0.5% @400~700nm
GL11-063-100-VIS
63.00
13.72
3.00
51.64
100.00
Ravg<0.5% @400~700nm
GL11-063-125-VIS
63.00
11.21
3.00
64.55
125.00
Ravg<0.5% @400~700nm
GL11-063-160-VIS
63.00
9.24
3.00
82.62
160.00
Ravg<0.5% @400~700nm
GL11-063-250-VIS
63.00
6.90
3.00
129.24
250.00
Ravg<0.5% @400~700nm
GL11-063-500-VIS
63.00
4.93
3.00
258.18
500.00
Ravg<0.5% @400~700nm
GL11-063-1000-VIS
63.00
3.96
3.00
516.50
1000.00
Ravg<0.5% @400~700nm
GL11-080-150-VIS
80.00
14.12
3.00
77.52
150.00
Ravg<0.5% @400~700nm
GL11-080-300-VIS
80.00
8.25
3.00
155.04
300.00
Ravg<0.5% @400~700nm
GL11-080-500-VIS
80.00
6.12
3.00
258.18
500.00
Ravg<0.5% @400~700nm
GL11-080-1000-VIS
80.00
4.60
3.00
516.82
1000.00
Ravg<0.5% @400~700nm
GL11-080-2000-VIS
80.00
3.76
3.00
1033.65
2000.00
Ravg<0.5% @400~700nm
GL11-100-160
