H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
Specifications
Brand Name :
TBNET
Model Number :
H12 Pro GNSS Receiver
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Contact us
Payment Terms :
L/C,T/T
Supply Ability :
100 Sets/ Month
Delivery Time :
2 weeks
Packaging Details :
Tool Case
Single Point Positioning Accuracy :
Horizontal: 1.5m ; Vertical: 2.5m
RTK Accuracy (RMS) :
Horizontal: 8 mm + 1 ppm; Vertical: 15 mm + 1 ppm
Static Accuracy (RMS) :
Horizontal: 2.5 mm + 0.5 ppm; Vertical: 5 mm + 0.5 ppm
Weight :
1.03 kg
Applications :
demanding surveying and positioning
Description
H12 Pro High-Precision IMU GNSS Receiver
Advanced Tilt Compensation and Full-Constellation Tracking
Why Choose the H12 Pro GNSS Receiver

The H12 Pro GNSS Receiver is a high-performance, precision device designed for demanding surveying and positioning applications. With full GNSS constellation support and automatic tilt compensation, it ensures exceptional accuracy in challenging field conditions. Featuring a Linux-based OS, voice prompts, a WEBUI interface, Wi-Fi connectivity, Type-C fast charging, and SIM card support, the H12 Pro provides seamless and reliable connectivity for a wide range of tasks.

H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
Advanced Tilt Compensation for Difficult Measurements

Equipped with the powerful NebulasIV GNSS SoC, the H12 Pro integrates advanced RF, baseband, and positioning algorithms to track over 40 satellites, ensuring reliable performance in complex environments. The IMU module allows for tilt compensation with up to 2.5 cm accuracy at tilt angles of up to 30°, with no need for calibration—just simple initialization for efficient operation.

H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
All-in-One, Compact Design

The H12 Pro integrates all the essential components for a complete solution: Bluetooth, UHF Radio, Wi-Fi, Internal Storage, GNSS Positioning, and IMU-based tilt compensation, plus a GSM Module—all packed into a single, compact device. It’s designed for flexibility, allowing seamless switching between Base and Rover modes to suit different field requirements.

H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
Easy Configuration with Linux OS

Configuring and monitoring the H12 Pro is simple with its Linux-based operating system. Users can easily access system status and adjust settings via a built-in web interface on any browser. With voice prompts and self-diagnostic functions, the device ensures ease of use and reliable operation with minimal maintenance.

H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking H12 Pro High Precision IMU GNSS Receiver Tilt Compensation Full Constellation Tracking
Technical Specifications
Accuracy Indicators Signal Tracking Initialization Performance
Single Point Positioning Accuracy
Horizontal: 1.5m
Vertical: 2.5m
RTK Accuracy (RMS)
Horizontal: 8 mm + 1 ppm
Vertical: 15 mm + 1 ppm
Static Accuracy (RMS)
Horizontal: 2.5 mm + 0.5 ppm
Vertical: 5 mm + 0.5 ppm
Velocity Accuracy
0.03 m/s
BDS
B1I / B2I / B3I / B1C / B2a / B2b
GPS
L1 C/A, L1C, L2C, L2P(Y), L5
GLONASS
G1, G2, G3
Galileo
E1, E5a, E5b, E6
QZSS
L1 C/A, L1C, L2C, L5, L6
NavIC
L5
SBAS
L1 C/A
Cold Start Time
< 12 seconds
Typical Initialization Time
< 5 seconds
RTK Initialization Reliability
> 99.9%
Reacquisition Time
< 1 second
Physical Performance Electrical Parameters Data Interfaces
Operating Temperature
-45°C to +75°C
Storage Temperature
-55°C to +85°C
Dimensions
Φ140mm x 141mm
Ingress Protection
IP67
Drop Resistance
Withstands drops of up to 2 meters
Buttons
2 buttons
Indicators
4 LED indicators
Humidity Resistance
100% non-condensing
Weight
1.03 kg
Power Consumption
Rover: ≤2.0W
Base Station: ≤2.2W
Battery Life
Rover: ≥20h
Base Station: ≥15h
Battery Capacity
10,000 mAh
Input Voltage
9-36 V DC
Radio Frequency Range
410-470 MHz
Radio Transmission Power
0.5 W / 1.5 W
Internal Storage
32 GB
Update Rate
Default 1 Hz, configurable up to 20 Hz
Physical Interfaces
USB Type-C, SIM card slot, TNC connector
Wireless Connectivity
Bluetooth 4.1 (backward compatible with BT 2.x)
Wi-Fi: IEEE 802.11 a/b/g/n
Data Output & Inertial Measurement
Differential Data
RTCM 3.x
Positioning Data
NMEA 0183
Static Data
Proprietary binary format
Tilt Angle Range
0-60°
Tilt Compensation Accuracy
≤ 2.5 cm (within 30° tilt)
