1.3x3m Building / Marine Board Panel Press Machine Single Layer Cold Pressing 50T
1.3x3m Building / Marine Board Panel Press Machine Single Layer Cold Pressing 50T
Specifications
Brand Name :
LONGYU
Certification :
ISO9001
MOQ :
1Set
Price :
USD:5000-10000
Payment Terms :
T/T
Supply Ability :
10Sets/month
Delivery Time :
30 days
Packaging Details :
Standard wooden case
Press Type :
Single Opening Cold Press
Bonding Method :
Pressure-Only at Room Temperature
Key Feature :
High Tonnage, Low Energy Use
Industry Role :
Final Assembly & Bonding Press
Machine weight :
2500 kg
Safety features :
Emergency Stop, Safety Guards
Machine type :
Hydraulic Press
Frame material :
High-strength Steel
Description

Single Layer Cold Press Machine for Building and Marine Board Panels, 50T Pressure, 1.3x3m Panel Size

1.3x3m Building / Marine Board Panel Press Machine Single Layer Cold Pressing 50T

Specifications:

Technical Parameter Specification
Model Number LY-12-50T
Main Application Cold press lamination/assembly of SPC, wood, insulation boards
Applicable Board Width 0.5 - 1.3 m (Customizable)
Applicable Board Length 1 - 3 m
Equipment Length 3.2 m (Customizable)
Press Pressure 50 Tons
Power Supply 380V 50Hz 3-Phase (Optional)
Max. Power Consumption 3.7 KW
Air Source Requirement 0.6 - 0.8 MPa

Notices:

1. The effectiveness of bonding depends on the correct adhesive selection (must be suitable for cold pressing) and sufficient press time (curing time). Follow adhesive manufacturer’s guidelines.

2. Ensure the panels are properly aligned and the adhesive is evenly applied before placing them into the press.

3. The machine applies significant force. Always ensure hands and tools are clear of the press area before initiating the cycle.

4. Regular checks of the hydraulic oil level and system for leaks are recommended for maintenance.

1.3x3m Building / Marine Board Panel Press Machine Single Layer Cold Pressing 50T

Applications:
Essential for high-pressure, room-temperature bonding processes:

1. Door Assembly: Pressing and gluing door skins (SPC, HPL) to solid or honeycomb cores to form ecological doors.

2. Panel Lamination: Bonding decorative SPC sheets to substrate boards like MDF, particleboard, or calcium silicate board.

3. Furniture & Component Pressing: Assemblying laminated panels for cabinets, tabletops, and other flat components.

1.3x3m Building / Marine Board Panel Press Machine Single Layer Cold Pressing 50T

1.3x3m Building / Marine Board Panel Press Machine Single Layer Cold Pressing 50T
