180 Degrees Flipping Turnover Laminator Machine For SPC Composite Boards
180 Degrees Flipping Turnover Laminator Machine For SPC Composite Boards
Specifications
Target Product :
Multi-layer Composite Panels
Controlsystem :
PLC control with touch screen
Applicableproducts :
Boxes, trays, cartons
Flipping angle :
180 degrees
Productname :
Flipping Machine
Packaging Details :
Standard wooden case
Brand Name :
LONGYU
Core Mechanism :
Panel Flipping & Alignment
Supply Ability :
10sets/month
Price :
8000.00-16000.00
Key Industry :
Door & Decorative Panel Manufacturing
Certification :
ISO9001
Delivery Time :
30-60 days
Payment Terms :
T/T
MOQ :
1Set
Warrantyperiod :
12 months
Description

Turnover Laminator Designed for SPC Composite Boards


Specifications:

Technical Parameter

Specification

Model Number

LY-10-1300

Main Application

Laminating SPC to wood, insulation boards, door cores

Applicable Board Width

1 - 1.3 m

Applicable Board Length

2 - 3 m

Applicable Board Thickness

1 - 3 mm (for each layer)

Standard Equipment Length

6.5 m (Customizable)

Lift Platform Load Capacity

2 tons (Customizable)

Flipping Mechanism Load

5 KG/m²

Productivity (for 3m board)

Up to 4 pieces per minute

Power Supply

380V 50Hz 3-Phase (Optional)

Air Source Requirement

0.6 - 0.8 MPa



180 Degrees Flipping Turnover Laminator Machine For SPC Composite Boards

180 Degrees Flipping Turnover Laminator Machine For SPC Composite Boards

Quick Detail:

  1. Precise Panel Overturning: This machine is engineered to accurately flip and bond one panel onto another with high stability.

  2. Wide Material Compatibility: Suitable for laminating SPC together with wood, thermal insulation boards, or ecological door cores.

  3. Fast Throughput: Delivers up to four 3-meter-long panels per minute, significantly boosting production efficiency.

  4. Robust & Durable Build: Comes with a 2‑ton lifting platform and supports a flipping load capacity of 5 kg per square meter.

  5. Compact Layout: Total length is only 6.5 meters (length can be customized), helping you make the best use of your workshop space.

180 Degrees Flipping Turnover Laminator Machine For SPC Composite Boards


Applications
Core machine for layered composite board manufacturing:

1. Ecological Door Production – Bonding SPC or HPL decorative layers onto wooden or honeycomb-based door cores.

2. Decorative Wall & Ceiling Panels – Attaching wear-resistant SPC surfaces to substrate materials such as MDF or calcium silicate boards.

3. Furniture Component Manufacturing – Producing composite panels used for cabinets, tabletops, and other furniture pieces.
